30
User's Guide ADI-6432R BNC © RME
14. Technical Specifications
14.1 Inputs
MADI
• Coaxial via BNC, 75 Ohm, according to AES10-1991
• High-sensitivity input stage (< 0.2 Vpp)
• Optical via FDDI duplex SC connector
• 62.5/125 and 50/125 compatible
• Accepts 56 channel and 64 channel mode, and 96k frame
• Single Wire: up to 64 channels 24 bit 48 kHz
• Double Wire: up to 32 channels 24 bit 96 kHz
• Lock range: 28 kHz – 54 kHz
• Jitter when synced to input signal: < 1 ns
• Jitter suppression: > 30 dB (2.4 kHz)
AES-3id
• 32 x, transformer-coupled, grounded, according to AES3-4-2009
• High sensitivity input stage (< 0.3 Vpp)
• SPDIF compatible (IEC 60958)
• Accepts Consumer and Professional format, copy protection will be ignored
• Single Wire: 32 x 2 channels 24 bit, up to 192 kHz
• Lock range: 28 kHz - 104 kHz, 162 kHz - 204 kHz
• Jitter when synced to input signal: < 1 ns
• Jitter suppression: > 30 dB (2.4 kHz)
Word Clock
• BNC, not terminated (10 kOhm)
• Switch for internal termination 75 Ohm
• Automatic Double/Quad Speed detection and internal conversion to Single Speed
• SteadyClock guarantees super low jitter synchronization even in varispeed operation
• Not affected by DC-offsets within the network
• Signal Adaptation Circuit: signal refresh by auto-center and hysteresis
• Overvoltage protection
• Level range: 1.0 Vpp – 5.6 Vpp
• Lock range: 28 kHz – 220 kHz
• Jitter when synced to input signal: < 1 ns
• Jitter suppression: > 30 dB (2.4 kHz)
14.2 Outputs
MADI
• Coaxial via BNC, 75 Ohm, according to AES10-1991
• Output voltage 600 mVpp
• Cable length coaxial: up to 100 m
• Optical via FDDI duplex SC connector
• 62.5/125 and 50/125 compatible
• Cable length optical: more than 500 m
• Generates 56 channel and 64 channel mode, and 96k frame
• Single Wire: up to 64 channels 24 bit 48 kHz
• Double Wire / 96k frame: up to 32 channels 24 bit 96 kHz
