DDE CTH175-102 [11/21] Front axle assembly

Front axle assembly

No. Parts no. Description

3 B896-15 Split washer 15

5 T000008 Washer

116 B6182-10 Nut M10

134 B6170-10 Nut M10

157 T002780 Front wheel

158 B1152-6 Oil cup M6

159 3301003 Shaft bushing

160 T002750 Right front shaft welding assembly

161 B5782-1690 Bolt M16*90

162 B97.1-16 Washer 16

T002701 Front axle bushing

No. Parts no. Description

164 T002760 Front axle and beam welding assembly

165 B93-16 Spring washer 16

166 B6170-16 Nut M16

167 T002790 Front axle swinging arm welding assembly

168 B5782-1060 Bolt M10*60

169 T002740 Universal join assembly

170 T002770 Left front shaft welding assembly

171 SQ10-RS-1 Joint bearing

172 T002741 Pull rod

173 SQ10-RS-1-L

Joint bearin

（Left rotation）

174 B6170-10

Nut M10（Left rotation）
