DDE CTH175-102 [8/21] Adjustment cutting height assembly

Adjustment cutting height assembly

No. Parts no. Description No. Parts no. Description

12 B5787-616 Bolt M6*16

135 T002007 Pin rod

14 B6182-6 Nut M6

136 S223008 Washer

22 B97.1-8 Washer 8 137 T002080 Left handing assembly

58 B6182-8 Nut M8 138 T002010 Pin

112 T002014 Washer 139 B5783-10110 Bolt M10*110

116 B6182-10 Nut M10 140 T002081 Rotation axis

118 T002060 Swinging arm welding assembly 141 T002083 Washer

119 T002006 Washer 142 T002082 Pin rod

120 T002001 Clamp arm 211 B879.5-530 Pin 5*30

121 3302058 Washer 10 212 T001620 Lever assembly

122 T002011 Plug pin 213 T001504 Shaft bushing

123 T002012 Limit fastener 214 T001519 Adjustment height limit plate

124 T002008 Washer 215 T001521 Adjustment height supporting seat

125 T002003 Deck rear swinging arm 216 T001506 Washer

126 T002005 Pull rod 221 T02070 Adjustment shaft welding assembly

127 T002090 Right hanging assembly 305 2100605 Button

128 B5782-860 Bolt M8*60 306 T001629 Handle sheath

129 3303018 Washer 307 T001625 Handle assembly

130 T002002 Fixed pin 308 T001621 Connecting rod

131 B6170-8 Nut M8 309 T001622 Tension spring

132 T002100 Deck front swinging arm 310 T001624 Pin

133 T002050 Swinging arm welding assembly 311 T001623 Toothed plate

134 B6170-10 Nut M10 312 S2501054 Star lock washer 8
