Mower assembly
2
No. Parts no. Description
1 T001800 Seat assembly
2 T003000 Steering wheel assembly
3 B896-15 Split washer 15
4 T000007 Washer
5 T000008 Washer
6 T002550 Rear wheel
7 T000006 Axle bushing
8 T005500 Plastic cover assembly
9 T000050 Direction pole assembly
10 B91-2550 Split cotter pin 2.5*25
11 T004555 Prevention hot cover
12 B5787-616 Bolt M6*16
13 T005070 Starter relay
14 B6182-6 Nut M6
15 3300106 Bolt 5/16-18UNC*3/4
16 T004560 Hush pipe assembly
17 T004500 Engine assembly
18 T002700 Front axle assembly
19 B5787-612 Bolt M6*12
20 T004550 Silencer
21 B5783-820 Bolt M8*20
22 B97.1-8 Washer 8
23 B93-8 Spring washer 8
No. Parts no. Description
24 T001000 Deck assembly
25 T000060 Collector channel assembly
26 T002000 Adjustment cutting height assembly
27 T001500 Mower-frame assembly
28 T003500 Grass catcher assembly
29 T000003 Seat spring
30 B70-840 Inside hexagonal bolt M8*40
31 T000004 Bolt
32 T000062 Half-collector channel(2)
33 T000061 Half-collector channel(1)
34 T006000 Foot control structure
35 T001558 Battery 12V 30AH
57 2800006 Washer
386 T001556 Battery rubber belt
387 XSS46-02A Key
389 T000051 Steering rod
390 B6170-12 Nut M12
391 SQ12-RS-1 Joint bearing 12
392 B6182-12 Nut M12
393 SQ12-RS-1-L
Joint bearing 12（Left rotation）
394 B6170-12
Nut M12（Left rotation）
395 B6182-12
Nut M12（Left rotation）
