ADJ Products, LLC - www.adj.com - Par Z Move User Manual Page 20

Service - This submenu has four functions: (1). Unit calibrattion (2). Activate the USB port

power (3). Update the unit software (4). Reset the unit to default settings.

NOTE: ONLY QUALIFIED TECHNICIANS SHOULD PERFORM THE CALIBRATION FUNCTION.

1. Access the main menu and press the UP or DOWN buttons so that “Personality” is highlighted then

press ENTER.

2. Use the UP or DOWN buttons to switch between “Eect Adjust”, “USB Port Power” “Update

Software”, and “Factory Restore”. Press the ENTER button to select the function you would like

to adjust.

- Eect Adjust - This is the calibration adjustment function. The calibration for Pan, Tilt, and Zoom

can be adjusted. NOTE: ONLY QUALIFIED TECHNICIANS SHOULD PERFORM THE CALIBRATION

FUNCTION.

- USB Port Power - This is the power activation for the USB port. This function needs to be activated

to use the UPDATE SOFTWARE function.

- Update Software - This function is used for any future software updates. Check www.adj.com

and this units webpage for any software updates. Download the software update to a ash stick

and plug the ash stick into the Flash Drive slot located on the front of the unit. Contact ADJ

customer service for help when updating software.

- Factory Restore - This function will allow you to return the unit to its factory settings. Use the

UP or DOWN buttons to switch between “YES” or “NO”. Selecting “YES” and pressing ENTER

will reset the unit to its factory settings.

3. Press the MENU button to exit.

Manual Control - This function will allow you to manually adjust the pan, tilt, shutter,

dimmer, zoom, and special functions. NOTE: The “No DMX Status” setting MUST be set to

“Manual” for this operational mode to work. Please see “No DMX Status” on page 16 for more

information.

1. Access the main menu and press the UP or DOWN buttons so that “Personality” is highlighted then

press ENTER.

2. Use the UP and DOWN buttons to switch between the available adjustable funcitons. Press the

ENTER button to select the function you would like to adjust.

3. Use the UP and DOWN buttons to adjust the values of the selected function. Press the ENTER

button after you have made your desired adjustments.

4. Repeat steps 2 & 3 to continue to make adjustments. Press the MENU button to exit.

Par Z Move Operating Instructions
