ADJ Products, LLC - www.adj.com - Par Z Move User Manual Page 23

Par Z Move Operating Instructions

Max Not Resettable - With this function you are able to check the highest temperature the

LED has reached. This LED temperature can NOT be reset, and could continue rise.

1. Access the main menu and press the UP or DOWN buttons so that “Information” is highlighted then

press ENTER.

2. Press the UP or DOWN buttons until “Fixture Temps” is highlighted and press ENTER.

3. Press the UP or DOWN buttons until “Max Not Resettable” is highlighted and press ENTER.

4. The xtues hightest temperature will now be displayed. Press the UP or DOWN buttons to switch

between farenheit and celsius. Press the MENU button to exit.

Reset LED Temps - With this function you can reset the MAX RESETTABLE LED temperature.

NOTE: When the temperature is reset, the temperature will revert to the CURRENT LED temperature.

1. Access the main menu and press the UP or DOWN buttons so that “Information” is highlighted then

press ENTER.

2. Press the UP or DOWN buttons until “Fixture Temps” is highlighted and press ENTER.

3. Press the UP or DOWN buttons until “Reset LED Temps” is highlighted and press ENTER.

4. Use the UP or DOWN buttons to set the pass code to “50” and press ENTER. The MAX RESETTABLE

LED temperature will now reset to the CURRENT LED temperature.

Fan Info. (RPM) - With this function you can check the speed of the base fan and LED

fan.

1. Access the main menu and press the UP or DOWN buttons so that “Information” is highlighted then

press ENTER.

2. Press the UP or DOWN buttons until “Fan Info.” is highlighted and press ENTER.

3. Use the UP or DOWN buttons to switch between “Base_fan” and “LED_fan”. Press the ENTER

button to select the fan speed you would like check.

4. The current speed of the select fan will now be displayed. Press the MENU button to exit.

DMX Values - With this function you can check the DMX values of each DMX channel that

is currently in use.

1. Access the main menu and press the UP or DOWN buttons so that “Information” is highlighted then

press ENTER.

2. Press the UP or DOWN buttons until “DMX Values” is highlighted and press ENTER.

3. Use the UP or DOWN buttons to nd the DMX channel you would like check and press ENTER.

The current DMX value of that channel will now be displayed. Press the MENU button to exit.
