5
English
8. When the machine is not use, the power source should
be disconnected.
9. Be sure to switch OFF and disconnect the attachment
plug from the receptacle to avoid a serious accident
before the depressed center wheel is assembling and
disassembling.
10. RCD
The use of a residual current device with a rated residual
current of 30 mA or less at all times is recommended.
11. Do not operate from a direct current power source,
booster or any other type of transformer. Doing so may
not only cause damage to the grinder, but may lead to
accidents.
12. Some mobile generators may not be usable with the
machine.
SYMBOLS
WARNING
The following show symbols used for the machine.
Be sure that you understand their meaning before
use.
G12SE3 / G13SE3: Disc Grinder
To reduce the risk of injury, user must read
instruction manual.
Always wear eye protection.
V Rated voltage
Alternating current
n
Rated speed
/min Revolution or reciprocations per minute
Switching ON
Switching OFF
Lock
Ϩ
Switch locks to the “ON” position.
Disconnect mains plug from electrical outlet
Warning
Class II tool
STANDARD ACCESSORIES
In addition to the main unit (1 unit), the package
contains the accessories listed in the below.
(1) Wrench .........................................................................1
(2) Side handle ...................................................................1
(3) Depressed center wheel ...............................................1
Standard accessories are subject to change without notice.
APPLICATIONS
○ Removal of casting fi n and fi nishing of various types of
steel, bronze and aluminum materials and castings.
○ Grinding of welded sections or sections cut by means of
a cutting torch.
○ Cutting of synthetic concrete, stone, brick, marble, and
similar materials.
SPECIFICATIONS
Model G12SE3 G13SE3
Voltage (by areas)* (230 V, 240 V)
Power input* 1400 W
Rated speed 11500 /min
Wheel
Outer dia. 115 mm 125 mm
Hole dia. 22.23 mm
Thickness 6 mm
Peripheral speed 80 m/s
Weight 2.5 kg
* Be sure to check the nameplate on product as it is subject
to change by areas.
NOTE
Due to HiKOKI’s continuing program of research and
development, the specifi cations herein are subject to
change without prior notice.
MOUNTING AND OPERATION
Action Figure Page
Fitting and adjusting the wheel guard 1 17
Fixing the side handle 2 17
Assembling depressed center wheel 3 18
Assembling cutting wheel and wheel
guard*
1
418
Assembling diamond wheel and
wheel guard*
1
518
Switch operation*
2
6 / 7 18, 19
Grinding angle and grinding method
8
19
Selecting accessories ― 20
*1 Optional
*2 Fig. 7 shows a power tool equipped with an on-lock
button.
0000BookG12SE3.indb50000BookG12SE3.indb5 2019/11/1910:35:142019/11/1910:35:14
