Use Instructions
2
1
3
4
Description of functions
POWER TIME
HUMIDITY
MIST
1. Take out the water tank assembly from the product.
2. Unscrew the water valve kit, put the water tank upright, align the
water filler with the faucet, open the faucet valve, fill the water tank with
water, and then tighten the water valve kit to complete the water filling.
3. Or unscrew the water valve kit, extend the water valve kit to a proper
position, lay the water tank flat, with the water inlet on the side of the
water valve aligned with the faucet, open the faucet valve, fill the water
tank with water, and then tighten the water valve kit to complete water
filling (this water filling method is applicable when the faucet is not
enough high to allow the entire water tank to be put upright).
4. Put the water tank assembly with water into the base, plug the plug
on the power cord into the socket, touch the "POWER" button to turn
this humidifier on and touch the "MIST" button to adjust the mist volume.
After power-on, the humidifier beeps once and enters the standby
mode, and the standby indicator lights up.
POWER button: If this button is pressed, this humidifier will beep once
and then start to work in “HI” mode by default, and meanwhile, the 4
strips on the display will light up, and the current humidity value will be
displayed in the numerical display area. This humidifier will be powered
off and the display will go out, but the standby indicator will stay on
once this button is pressed.
Note: In the power-on mode, the display will go out if the “POWER”
button is pressed and held for 3s, and then light up again if any one of
the buttons is pressed.
03(HI) 02(INT)
01(LO)
Empty protection: In case of insu翿cient water, the buzzer will beep three
times, the low water level indicator will flash in red on the display, and the
display will stay on; after the water tank is filled with water, the low water
level indicator will go out and immediately return to normal working status.
Note: If the auto constant-humidity function is activated, the humidifier will
work in the “HI” mode by default, and after reaching the set humidity value,
the humidifier will enter the standby mode; if the humidity is lower than the
set value, the humidifier will activate the humidity function.
MIST button: Press this button to adjust the mist volume in “HI”, “INT” and
“LO” modes, as shown in the following table. After the mode has been set,
the corresponding mode bar on the display will light up (one bar for
“LO”mode, 2 bars for “INT” mode, and 4 bars for “HI” mode), and the
current humidity value will be displayed in the numerical display area.
TIME button: The timing function will be deactivated by default after
power-on. When the humidifier is working, the timing function will be
activated for switching as shown below if this button is pressed. After the
set time has been selected, the set time will flash for 3s, the humidifier will
enter the timed working mode, the timing icon will light up, and the
current humidity value will be displayed in the numerical display area; when
the set time expires,the humidifier will enter the standby mode; if you need
to cancel the timing, press the TIME button and adjust the time to 00, and
then the set time will flash for 3s; 3s later, the timing will be deactivated,
and the timing icon goes out.
1h 2h
11h
12h
······
‘00’ timing setting deactivated
HUMIDITY button: After power-on, the auto constant-humidity function will
be deactivated by default. When the humidifier is working, the constant-hu-
midity function will be activated for switching as shown below if this button
is pressed. After the desired humidity value is selected, the value will flash for
3s, then the humidifier will enter the constant-humidity mode, and the
corresponding humidity icon, humidity value and humidity unit symbol will
light up; to deactivate the auto constant-humidity function, adjust the
humidity value to --, then the -- will flash for 3s, and the icon will go out.
45 50
85
90
······
Constant-humidity setting deactivated
Note: This humidifier should be consistent with the remote control unit in
terms of function settings of all the buttons stated above; in addition, be
sure to pull out the power cord plug when this humidifier is not working.
HUMIDITY
Plan of four
function keys
Magnetic area
Replacement position
for button battery
The remote control unit can
be sucked to the front top
3 4
