6 Trigger "0/OFF" / "I/ON"
7 Storage for spray lance
8 High-pressure hose
9 *Plug 'n' Clean detergent bottle
10 Storage / parking position for high-pressure gun
11 3-in-1 multi-jet spray lance with 3 spray types (see
also chapter Smart Control System)
12 Smart Control high-pressure gun
13 LCD display (see also chapter LCD display)
14 Battery compartment lock
15 Battery compartment
16 “+/-” buttons for pressure control
17 High-pressure gun lock
18 Button for separating the high-pressure hose from
the high-pressure gun
19 High-pressure gun lever
20 Transport handle, telescoping
21 Carrying handle
22 Hose holder
23 High pressure hose reel
24 Crank handle for hose reel
25 Type plate
26 Accessory compartment
27 Hook for net attachment
28 Accessory compartment net
29 Mains connection with mains plug
30 Supplied screws and dowels
31 Water connection coupling
32 **Garden hose (fabric reinforced, diameter at least
1/2 inch (13 mm), length at least 7.5 m, with com-
mercially available quick coupling)
33 **KÄRCHER suction hose for water supply from
open containers (order no. 2.643-100.0)
34 *Foam nozzle with detergent container
The detergent is sucked out of the container to pro-
duce a strong detergent foam.
35 *Rotating washing brush (e.g. for washing cars)
* optional, ** additionally required
LCD display
Illustration C
1 Area of application (1-SOFT / 2-MEDIUM / 3-HARD
with 2 pressure levels each)
2 BOOST function indicator
3 Spray type recommendation (flat stream/detergent/
dirt grinder)
4 Display Bluetooth
®
connection
5 Signal strength status (four levels)
6 Battery status (empty, almost empty, medium, full)
7 Detergent level (1 / 2 / 3)
Supplied screws and dowels
Illustration D
1 Stand dowels (2 pieces)
2 Screw M 4x20 (2 pieces)
3 Screw M 4x22 (2 pieces)
4 Screw M 4x16 (8 pieces)
Safety devices
CAUTION
Missing or modified safety devices
Safety devices are provided for your own protection.
Never modify or bypass safety devices.
Power switch
The power switch prevents unintentional operation of
the device.
High-pressure gun lock
The lock locks the lever of the high-pressure gun and
prevents the device from starting unintentionally.
Auto-stop function
If the lever of the high-pressure gun is released, the
pressure switch turns off the pump and the high-pres-
sure jet stops. The pump switches on again when the le-
ver is pressed.
Motor circuit breaker
The motor circuit breaker shuts off the device if power
consumption it too high.
Symbols on the device
Assembly
For the illustrations, refer to the graphics page.
Place the screws provided and matching screwdriver at
the ready.
Fit the supplied loose parts onto the device before start-
ing up the device.
Fitting the wheels
1. Insert the wheels.
Note
Pay attention to the alignment of the hole.
Illustration E
2. Secure the wheels with 1 screw each.
Mounting the stand
1. Insert the stand.
Illustration F
2. Insert the 2 dowels into the holes as far as they will
go.
3. Secure the base with 2 screws.
Installing the spray lance storage
1. Hang the spray lance storage in position.
2. Secure the storage with 2 screws.
Illustration G
3. Secure the cover with 4 screws.
Illustration H
Mounting the transport handle
1. Attach the transport handle.
Illustration I
2. Secure the transport handle with 2 screws.
Mounting the accessory net
1. Hang the accessory net on the hooks.
Illustration J
Do not aim the high-pressure jet may at per-
sons, animals, live electrical equipment or
the device itself.
Protect the device against frost.
The device may not be connected to the
public drinking water network.
