FOOD WASTE DISPOSER INSTALLATION, CARE & USE MANUAL

Read through the entire Installation, Care & Use manual before installing the disposer. Determine

which of the tools, materials, and accessories you will need before you begin. Make sure you have all

necessary disposer parts before installing the disposer.

NOTE: The PREMIUM models grind much ner than any other disposer. For this reason you may notice

that it takes a little longer to grind some food waste. Due to the PREMIUM model’s microprocessor,

users will experience a fractional second delay when starting on all PREMIUM models. This is

completely normal.

** Additional screws (For sinks with a wall thickness greater than 1 mm.)

1. CHECK INSTALLATION DIMENSIONS (Fig.2.1)

1. Disposer height

2. Distance from bottom of sink bowl to centerline of discharge outlet. (Add 12 mm when stainless

steel sink is used.)

3. Distance from centerline of the discharge outlet to end of discharge tube.

4. Disposer width

5. Distance from disposer vertical centerline to centerline of trap connection.

To properly drain and prevent standing water in the disposer, the waste pipe entering the wall must

be lower than the disposer discharge outlet.

4. Push sink ange up through sink hole and remove it (Fig.3.2).

5. Clean sink ange area of any putty or other debris.

NOTE: The sink hole may have to be enlarged to accept the disposer sink ange. Sink hole

enlargement tools are available from your dealer.

3.DISASSEMBLE NEW DISPOSER MOUNTING ASSEMBLY (Fig.4.1)

1. Turn the assembly, loosen the three screws (1).

2. Turn the tightening pressing plate (2) so that the half round hole (3) coincide with the locking dent

(4) on the sink ange.

PARTS LIST (Fig.1.1)

MOUNTING ASSEMBLY

7. Locking plate

8. Tightening pressing plate

14. Discharge Outlet

15. Wrenchette
