3. Remove loose knockout plug from inside disposer.

If you have a sink overow, it should be connected to the overow inlet on the tailpipe (Fig.7.2).

To connect the overow, remove the plug in the tailpipe by unscrewing the overow connector cap

(Fig.7.3).

7. ATTACH DISCHARGE TUBE TO WASTE DRAIN PIPE

• Wearing safety glasses is recommended during the installation of the food waste disposer.

• PREMIUM350 must be connected to the supplied tailpipe with the supplied spring type hose clamp

(Fig. 9.1). Failure to use the supplied tubes and spring type hose clamp will void the warranty and

DISCHARGE TUBE INSTALLATION (See Figure 8.1)

1. Place discharge tube (2) into Anti-Vibration Tailpipe Mount. Secure with spring type hose clamp (1).

(Fig.8.1)

2. Rotate disposer so that discharge tube is aligned with drain trap. (To prevent leaks, do not pull or

bend discharge tube to drain trap.) If discharge tube is too short, you can purchase an extension from

hardware store. (Disposer must remain in vertical position to prevent vibration.)

3. Place nut, then ferrule on discharge tube (not supplied) and tighten on drain trap.

(If you have a double sink, use separate drain traps for both sides of sink.)

4. Ensure lower mounting ring is still securely locked over ridges on mounting ange. (Fig.8.2)

5. Place stopper in sink in close position. Fill sink with water, remove stopper and check for leaks.

(grounded) receptacle.

• Do not modify plug provided with unit (if applicable).

• Improper connection of equipment earth (grounded) conductor can result in electric shock.

• All wiring must comply with local electrical codes.

• Do not attach earth wire (ground wire) to gas supply pipe.

• Do not reconnect electrical current at main service panel until proper earth (grounded) outlets are

installed.

• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly

qualiedpersons in order to avoid a hazard.

NOTE: You must have access to an earth (grounded) wall socket. Any additional socket should be
