8
If a wall switch (not supplied) is required for your installation, it must have on/o markings and be
installed by a qualied tradeperson. It should be located in a convenient position above the work
surface with a minimum of 3 mm contact separation between each pole (20 ADP switches to BS
3676). Connect to a 20 amp earth (grounded) wall socket (2) using a 20 amp cable. (Fig.9.1)
Air Switch:
The PREMIUM disposers include a built-in air switch (Brushed Nickel and Chrome nishes). An air
switch activates/turns o the unit by sending a pulse of air to the control box.
AIR SWITCH INSTALLATION
1. Drill a 33 mm wide hole into the kitchen work top, or the corner of the sink unit, at the most
convenient point for use.
Some sink units may already have a suitable hole in them which can be exposed by removing the cap.
2. Remove the nut from the push button bellows, while keeping the stainless steel washer and rubber
gasket in place.
Push one end of the PVC tubing onto the spout of the push button bellows, feed the other end of the
tube through the hole in the work top and through the nut underneath the work top. (Fig.9.2)
3. Fit the push button bellows in the hole and then screw up the nut underneath the work top until it
is hand tight. Do not use a wrench to tighten the nut. (Fig.9.3)
4. Take the other end of the air tube and rmly push it over the spout of the air switch, which is
located on the underside of the waste disposer. (Fig.9.4)
DISABLING THE AIR SWITCH
The air switch can be disabled if wall switch operation is preferred.
The disposer is shipped with the switch in the “o ” position.
1. Push one end of the PVC tubing provided onto the spout of the push button bellows. (Fig.9.2)
2. Take the other end of the air tube and push it over the spout of the air switch, which is located on
the underside of the waste disposer. (Fig.9.4)
3. Depress the air switch one time until you hear the switch “click.”
Remove and discard the push button bellows and PVC tubing. The disposer may now be activated by
a wall switch.
The disposer installation is complete. Read all operating and safety instructions in Instruction 10
before operating the disposer.
10. IMPORTANT SAFETY INSTRUCTIONS
When using electronic appliances, basic precautions are always to be followed, including:
• If the air switch or wall switch fails to shut o or turn on disposer, unplug power cord plug and
contact your qualied trade person.
• This product is designed to dispose of normal household food waste; inserting materials other than
food waste into disposer could cause personal injury and/or property damage. To reduce the risk of
injury, do not use the sink containing the disposer for purposes other than food preparation (such as
baby bathing or washing hair).
• This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of appliance by a person responsible for their safety. Children should be
supervised to ensure that they do not play with disposer. To reduce the risk of injury, close supervision
is required when an appliance is used near children.
• When attempting to loosen a jam in the food waste disposer, switch o or unplug the appliance
before attempting to free a jammed rotor. Use a self service wrenchette as described in the Releasing
Disposer Jam section.
