Hikoki RB40SA [7/40] English
![Hikoki RB40SA [7/40] English](/views2/2030318/page7/bg7.png)
6
English
MOUNTING AND DISMOUNTING THE NOZZLE
AND DUST BAG
1. Mounting the NozzIe
Insert the pin located outside the nozzle into the notch
provided on the blast port, and fully turn the nozzle in
the direction indicated by the arrow in Fig. 1.
To dismount the nozzle.,folIow the above procedures in
reverse.
2. When using the Blower for dust collection
(1) Mounting the Dust Bag
Mount the dust bag on the blast port, following the same
procedure described above for mounting of the nozzle
(Fig. 2).
(2) Mounting the nozzle
Insert the pin located on the outside of the nozzle into
the notch provided on the suction port, and fully turn the
nozzle in the direction indicated by the arrow in Fig. 3.
HOW TO USE THE BLOWER
1. By pulling the trigger and pushing the stopper, the
switch will remain in the ON position even when the
trigger is released, promoting effi cient, continuous
operation. By pulling the trigger again, the stopper is
disengaged and the switch is turned OFF when the
trigger is released.
2. On the RB40VA, the pulling force on the switch changes
the amount of blow force. The maximum amount of
blow force can be adjusted with the speed control dial
(Fig. 4).
3. An excessively large volume of dust in the dust bag
will reduce the dust collecting effi ciency of the blower.
Frequently empty the dust bag to ensure maximum dust
collecting effi ciency.
MAINTENANCE AND INSPECTION
1. Inspecting the mounting screws
Regularly inspect all mounting screws and ensure that
they are properly tightened. Should any of the screws
be loose, retighten them immediately. Failure to do so
could result in serious hazard.
2. Inspecting the carbon brushes (Fig. 5)
The motor employs carbon brushes which are
consumable parts. Since an excessively worn carbon
brush can result in motor trouble, replace the carbon
brush with a new one having the same carbon brush
No. shown in the fi gure when it becomes worn to or
near the “wear limit”. In addition, always keep carbon
brushes clean and ensure that they slide freely within
the brush holders.
3. Replacing carbon brushes
Disassemble the brush cap with a screwdriver. The
carbon brush can then be easily removed.
4. Maintenance of the motor
The motor unit winding is the very “heart” of the power
tool.
Exercise due care to ensure the winding does not
become damaged and/or wet with oil or water.
5. Service parts list
A: Item No.
B: Code No.
C: No. Used
D: Remarks
CAUTION
Repair, modifi cation and inspection of HiKOKI Power
Tools must be carried out by a HiKOKI Authorized
Service Center.
This Parts List will be helpful if presented with the tool to
the HiKOKI Authorized Service Center when requesting
repair or other maintenance.
In the operation and maintenance of power tools, the
safety regulations and standards prescribed in each
country must be observed.
MODIFICATIONS
HiKOKI Power Tools are constantly being improved
and modifi ed to incorporate the latest technological
advancements.
Accordingly, some parts (i.e. code numbers and/or
design) may be changed without prior notice.
GUARANTEE
We guarantee HiKOKI Power Tools in accordance with
statutory/country specifi c regulation. This guarantee does
not cover defects or damage due to misuse, abuse, or
normal wear and tear. In case of complaint, please send
the Power Tool, undismantled, with the GUARANTEE
CERTIFICATE found at the end of this Handling instruction,
to a HiKOKI Authorized Service Center.
NOTE
Due to HiKOKI’s continuing program of research and
development, the specifi cations herein are subject to
change without prior notice.
Information concerning airborne noise and vibration
The measured values were determined according to
EN60745 and declared in accordance with ISO 4871.
The typical A-weighted sound pressure level: 84 dB (A).
Uncertainty KpA: 3 dB (A).
Wear ear protection.
The typical weighted root mean square acceleration value
does not exceed 2.5 m/s
2
.
