28
TECHNICAL PASSPORT ENGLISH
Gas- electric hob
INSTRUCTIONS FOR THE
INSTALLER
Installation
This appliance is not provided with
a combustion product discharge. It is
recommended that it be installed in
sufciently aerated places, in terms of
the laws in force. The quantity of air
which is necessary for combustion must
not he below 2. 0 m
3
/h for each kW of
installed power.
See table of burner power.
Positioning
 The appliance can be tted into
a working area as illustrated on the
corresponding gure. Before positioning
the hob, t the seal around the entire
peripnery of the hole cut in the worktop
Fig. 2
 That the plant is tted with an
efcient earth connection, following
the standards and law provisions in
force.
 The earth connection is
compulsory in terms of the law. Should
there be no cable and/or plug on the
equipment, use suitable absorption
material for the working temperature as
well, as indicated on the matrix plate.
Under no circumstance must the cable
reach a temperature above 50 °C of the
ambient temperature. Should a direct
connection to the network be required,
it will be necessary to interpose an
omnipolar switch with minimum
aperture between the 3 mm. contacts,
dimensioned to bear the plate load and
it must follow the standards in force
(the yellow/green earth cable must
not be interrupted by the switch). The
plug or omnipolar switch must be easily
reached on the installed equipment.
 The manufacturers decline any
responsibility in the event of non-
compliance with what is described
above and the accident prevention
norms not being respected and followed.
 If the mains cable becomes
damaged, replace it immediately with a
cable or special cable set obtained from
the manufacturer or from after sales
service.
GAS CONNECTION
(Fig. 3) Connect the appliance to
the gas cylinder or to the installation
according to the prescribed standards
in force, and ensure beforehand, that
the appliance matches the type of gas
available. Otherwise, see «Adaptation
to various types of gas». Furthermore,
check that the feed pressure falls within
the values described on the table: «User
chacteristics».
