6 English

housing until the latch clicks into place. Before installation, check the battery

charge using the indicator.

3. To charge the battery, use the charger which is supplied with the tool (if

available) or a charger with a maximum output voltage of 5 V and a USB-C

connector. To connect the charger, use the connector on the battery (10).

Gently pull the rubber cap. The cap is attached to the battery housing with

one edge. Don’t tear it off! Check the battery power with the indicator.

4. If you do not use the line laser for a long time (more than 24 hours),

disconnect the battery. Otherwise the battery may be discharged below the

permissible voltage. This may result in battery failure.

WARNING: Do not leave the tool (battery) unattended while using

charger. Parameters of the charger must correspond to the parameters

of domestic electricity. Output voltage must be no more than 5V. Do

not disassemble or heat the battery.

OPERATION

1. Set the pendulum switch (7) down to the (ON) position. Upper horizontal

line is ON. If the switch is in the (ON) position, the line laser is switched on

and a pendulum in a free position (is unlocked). The position of the pendulum

switch (8) (OFF) means that the line laser is switched off and the pendulum is

locked. If the line laser is set beyond the self-leveling range, an audible signal

will sound, the laser lines and the indicator (14) will blink 1 time per second.

2. Laser beams can be turned on and off separately. To save battery power,

turn on only the laser beams that are necessary for operation.

• press button (4) once – horizontal laser beam is ON. Press button (4)

once again – horizontal laser beam is OFF.

• press button (5) once – side vertical laser beam is ON. Press button

(5) once again – side vertical laser line is OFF.

• press button (6) once – front vertical laser line is ON. Press button (6)

once again - front vertical laser line is OFF.
