34
CHAIN SAW OPERATING MANUAL
GB
è
- Cut with the chain sharp and taught.
- Into a cut that has already been
started, insert the chain at top speed
and very attentively.
- Extract the bar from the cut only with
the chain in movement.
SAFETY DEVICES ON THE CHAINSAW
The chainsaw must be held with the
left hand on the front handle and
the right on the rear handle (this
applies to left handed people, too).
The safety devices have been de-
signed to function with the hands
in those positions.
Your chainsaw is provided with the
following safety devices.
B1 - THROTTLE TRIGGER LOOK-
OUT (see Fig.1 part.9) prevents acci-
dental operation of the throttle trigger.
THROTTLE TRIGGER (Fig.1 part.10).
DANGER: Warning. The cutting chain
may continue to rotate for a certain time
after the throttle trigger has been re-
leased.
B2 – STOP SWITCH (Fig.1 part.12)
With the lever down [STOP ] the
engine is stopped.
B3- SAFETY CHAIN BRAKE Your
chainsaw is provided with a safety chain
brake (Fig. 1 part. 7) which can stop
the chain in a fraction of a second (in the
event of a kickback).
B4 – CHAIN CATCHER (Fig. 1 part.
2). This device prevents the chain from
being thrown in the event of it breaking
(or coming out of the bar) during
operation.
On each occasion, before use
check that all the safety devices
function perfectly.
If they do not, do not use the
chainsaw and contact a qualified
service centre for the repair. Read
chapter 8.3 “CHAIN BRAKE”.
3. DESCRIPTION OF PARTS OF THE
MACHINE DESCRIPTION FIG.1
1) Rear hand-guard
2) Chain catcher
3) Chain
4) Chain guide bar
5) Bar cover
6) Spike
7) Front hand guard / Chain safety brake
lever
8) Front handle
9) Throttle trigger look-out
10) Throttle trigger
11) Rear handle
12) Engine stop switch (STOP)
14) Choke/throttle advance knob
15) Carburettor setscrew
16) Fuel tank cap
17) Chain oil tank cap
18) Starter cord handle
19) Bar locking nut
20) Chain tension screw
21) Chain tension tooth
22) Starter
23) Top cover
24) Exhaust silencer
25) Chain cover
26) Top cover screw
27) Fuel primer
28) Decompression valve
ENGLISH
