Bosch GSR 18 V-EC TE 0.601.9C8.007 [13/160] Battery charging
English | 13
Bosch Power Tools 1 609 92A 2DB | (6.10.16)
Noise/Vibration Information
Sound emission values determined according to
EN 60745-2-1.
Typically the A-weighted sound pressure level of the product
is 75 dB(A). Uncertainty K=3 dB.
The noise level when working can exceed 80 dB(A).
Wear hearing protection!
Vibration total values a
h
(triax vector sum) and uncertainty K
determined according to EN 60745:
Screwdriving without impact: a
h
<2,5m/s
2
, K=3 m/s
2
.
The vibration level given in this information sheet has been
measured in accordance with a standardised test given in
EN 60745 and may be used to compare one tool with anoth-
er. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or insertion tools or is
poorly maintained, the vibration emission may differ. This
may significantly increase the exposure level over the total
working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working
period.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work pat-
terns.
Declaration of Conformity
We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with all rele-
vant provisions of the directives 2009/125/EC (Regulation
1194/2012), 2011/65/EU, 2014/30/EU, 2006/42/EC in-
cluding their amendments and complies with the following
standards: EN 60745-1, EN 60745-2-1, EN 60745-2-2,
EN 50581.
Technical file (2006/42/EC) at:
Robert Bosch Power Tools GmbH, PT/ECS,
70538 Stuttgart, GERMANY
Robert Bosch Power Tools GmbH
70538 Stuttgart, GERMANY
Stuttgart, 01.01.2017
Assembly
Battery Charging
Use only the battery chargers listed on the accessories
page. Only these battery chargers are matched to the lith-
ium-ion battery of your power tool.
Note: The battery supplied is partially charged. To ensure full
capacity of the battery, completely charge the battery in the
battery charger before using your power tool for the first time.
The lithium-ion battery can be charged at any time without re-
ducing its service life. Interrupting the charging procedure
does not damage the battery.
The lithium-ion battery is protected against deep discharging
by the “Electronic Cell Protection (ECP)”. When the battery is
empty, the machine is switched off by means of a protective
circuit: The inserted tool no longer rotates.
Do not continue to press the On/Off switch after the
machine has been automatically switched off. The bat-
tery can be damaged.
Observe the notes for disposal.
Removing the battery
The battery 9 is equipped with two locking levels that should
prevent the battery from falling out when pushing the battery
unlocking button 10 unintentionally. As long as the battery is
inserted in the power tool, it is held in position by means of a
spring.
To remove the battery 9, press the unlocking button 10 and
pull out the battery toward the front. Do not exert any force.
Changing the Tool (see figure A)
Before any work on the machine itself (e. g. mainte-
nance, tool change, etc.) as well as during transport
and storage, remove the battery from the power tool.
There is danger of injury when unintentionally actuating
the On/Off switch.
Permitted ambient
temperature
– during charging
– during operation
**
and
during storage
°C
°C
0... +45
-20... +50
Recommended batteries
GBA 18V..
GBA 18V... W
Recommended chargers
AL 18..
GAL 3680
Recommended chargers for
wireless charging batteries
GAL 18... W
Cordless Screwdriver GSR 18 V-EC TE
*Depending on the battery pack being used
** Limited performance at temperatures <0 °C
Henk Becker
Executive Vice President
Engineering and
Manufacturing
Helmut Heinzelmann
Head of Product Certification
PT/ECS
OBJ_BUCH-1908-003.book Page 13 Thursday, October 6, 2016 9:51 AM
