Zalman FX100 [10/13] Caution
![Zalman FX100 [10/13] Caution](/views2/1110940/page10/bga.png)
9
.COM
AMD Washer
Nut
Clip Support
④ Take away the fixed Clip support from the motherboard, and then install
the included Clip support using Nipple A, AMD’s washer(1mm) and nuts.
※After installing the Clip Support, please mount the CPU cooler as following.
C. Cooler Installation
① Apply a suitable amount of
the included Thermal Grease
on the CPU’s surface.
Intel or AMD CPU
Please make a note of
the orientation of the Clip Support.
O
X
Caution
