Gigabyte GA-HA65M-D2H-B3 (REV. 1.0) [21/104] 7 internal connectors

- 21 - Hardware Installation

1-7 Internal Connectors

Read the following guidelines before connecting external devices:

• First make sure your devices are compliant with the connectors you wish to connect.

• Before installing the devices, be sure to turn off the devices and your computer. Unplug the

power cord from the power outlet to prevent damage to the devices.

• After installing the device and before turning on the computer, make sure the device cable has

been securely attached to the connector on the motherboard.

1112

813

1) ATX_12V 8) F_PANEL

2) ATX 9) F_AUDIO

3) CPU_FAN 10) SPDIF_O

4) SYS_FAN 11) F_USB1/F_USB2

5) BAT 12) COM

6) GSATA3_4/5 13) CLR_CMOS

7) SATA2_0/1/2/3 14) PHASE LED
