- 39 - BIOS Setup
Command Rate(CMD)
Options are: Auto (default), 1~3.
>>>>> Channel A/B Misc Timing Control
IO Latency
Options are: Auto (default), 1~31.
Round Trip Latency
Options are: Auto (default), 1~255.
Advanced Voltage Settings
>>> CPU
CPU Vcore
The default is Auto.
Dynamic Vcore(DVID)
ThisoptioniscongurableonlywhenCPU Vcore is set to Normal. The default is Auto.
QPI/Vtt Voltage
The default is Auto.
Graphics DVID
The default is Auto.
>>> MCH/ICH
PCH Core
The default is Auto.
DRAM Voltage
The default is Auto.
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
Advanced Voltage Settings
****** Mother Board Voltage Control ******
Voltage Types Normal Current
-----------------------------------------------------------------------------
>>> CPU
CPU Vcore 1.220V [Auto]
x Dynamic Vcore(DVID) +0.000V Auto
QPI/Vtt Voltage 1.050V [Auto]
Graphics DVID +0.000V [Auto]
>>> MCH/ICH
PCH Core 1.050V [Auto]
DRAM Voltage 1.500V [Auto]
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
Содержание
483- Ga ha65m d2h b3
- User s manual
- Motherboard
- Ga ha65m d2h b3
- Feb 25 2011
- Documentation classifications
- Identifying your motherboard revision
- Disclaimer
- Copyright
- Box contents optional items
- Table of contents
- Chapter 2 bios setup 9
- Chapter 1 hardware installation
- Ga ha65m d2h b3 motherboard layout ga ha65m d2h b3 motherboard block diagram
- Chapter 5 appendix 7
- Chapter 4 unique features 9
- Chapter 3 drivers installation 5
- Optional items
- Box contents
- Ga ha65m d2h b3 motherboard layout
- Ga ha65m d2h b3
- Ga ha65m d2h b3 motherboard block diagram
- Chapter 1 hardware installation
- 1 installation precautions
- 2 product specifications
- 3 installing the cpu and cpu cooler
- 3 1 installing the cpu
- 3 2 installing the cpu cooler
- 4 installing the memory
- 4 1 dual channel memory configuration
- 4 2 installing a memory
- 5 installing an expansion card
- Usb 2 1 port
- 6 back panel connectors
- Ps 2 keyboard mouse port
- Hdmi port
- Dvi d port
- D sub port
- Mic in jack pink
- Line out jack green
- Line in jack blue
- Dual display configurations for the onboard graphics
- Center subwoofer speaker out jack orange
- Usb 3 2 port
- Side speaker out jack gray
- Rj 45 lan port
- Rear speaker out jack black
- 7 internal connectors
- With the use of the power connector the power supply can supply enough stable power to all the com ponentsonthemotherboard beforeconnectingthepowerconnector firstmakesurethepowersupply is turned off and all devices are properly installed the power connector possesses a foolproof design connect the power supply cable to the power connector in the correct orientation the 12v power con nector mainly supplies power to the cpu if the 12v power connector is not connected the computer will not start
- To meet expansion requirements it is recommended that a power supply that can withstand high power consumption be used 500w or greater if a power supply is used that does not provide the required power the result can lead to an unstable or unbootable system
- Hardware installation 22
- 2 atx_12v atx 2x2 12v power connector and 2x12 main power connector
- The motherboard has a 4 pin cpu fan header cpu_fan and a 4 pin sys_fan most fan headers possess a foolproof insertion design when connecting a fan cable be sure to connect it in the correct orientation the black connector wire is the ground wire the motherboard supports cpu fan speed con trol which requires the use of a cpu fan with fan speed control design for optimum heat dissipation it is recommended that a system fan be installed inside the chassis
- Heating overheating may result in damage to the cpu or the system may hang
- Headers
- Be sure to connect fan cables to the fan headers to prevent your cpu and system from over
- Bat battery
- 4 cpu_fan sys_fan fan headers
- 23 hardware installation
- Thesefanheadersarenotconfigurationjumperblocks donotplaceajumpercaponthe
- Thebatteryprovidespowertokeepthevalues suchasbiosconfigurations date andtimeinformation in the cmos when the computer is turned off replace the battery when the battery voltage drops to a low level or the cmos values may not be accurate or may be lost
- Sata2_0 1 2 3 sata 3gb s connectors controlled by intel h61 chipset
- The sata connectors conform to sata 3gb s standard and are compatible with sata 1 gb s standard each sata connector supports a single sata device
- The sata connector conform to sata 6gb s standard and are compatible with sata 3gb s and sata 1 gb s standard each sata connector supports a single sata device the marvell 88se9172 chip supportsraid0andraid1 refertochapter5 configuringsataharddrive s forinstructions onconfiguringaraidarray
- Hardware installation 24
- Gsata3_4 5 sata 6gb s connectors controlled by marvell 88se9172 chip
- Araid0orraid1configurationrequirestwoharddrives
- F_panel front panel header
- Some chassis provide a front panel audio module that has separated connectors on each wire
- Ously if you want to mute the back panel audio only supported when using an hd front panel audiomodule refertochapter5 configuring2 4 5 7 channelaudio
- Instead of a single plug for information about connecting the front panel audio module that has different wire assignments please contact the chassis manufacturer
- Hardware installation 26
- Front panel audio module refer to the instructions on how to activate ac 97 functionality via theaudiosoftwareinchapter5 configuring2 4 5 7 channelaudio
- F_audio front panel audio header
- Audio signals will be present on both of the front and back panel audio connections simultane
- This header supports digital s pdif out and connects a s pdif digital audio cable provided by expan sion cards for digital audio output from your motherboard to certain expansion cards like graphics cards and sound cards for example some graphics cards may require you to use a s pdif digital audio cable for digital audio output from your motherboard to your graphics card if you wish to connect an hdmi display to the graphics card and have digital audio output from the hdmi display at the same time for information about connecting the s pdif digital audio cable carefully read the manual for your expan sion card
- Thefrontpanelaudioheadersupportsintelhighdefinitionaudio hd andac 97audio youmayconnect your chassis front panel audio module to this header make sure the wire assignments of the module con nector match the pin assignments of the motherboard header incorrect connection between the module connector and the motherboard header will make the device unable to work or even damage it
- The front panel audio header supports hd audio by default if your chassis provides an ac 97
- Spdif_o s pdif out header
- 27 hardware installation
- When the system is in s4 s5 mode only the usb ports routed to the f_usb1 header can sup port the on off charge function
- Theheadersconformtousb2 1 specification eachusbheadercanprovidetwousbportsviaan optional usb bracket for purchasing the optional usb bracket please contact the local dealer
- The com header can provide one serial port via an optional com port cable for purchasing the op tional com port cable please contact the local dealer
- F_usb1 f_usb2 usb headers
- Do not plug the ieee 1394 bracket 2x5 pin cable into the usb 2 1 header prior to installing the usb bracket be sure to turn off your computer and unplug the power
- Cord from the power outlet to prevent damage to the usb bracket
- Com serial port header
- Phase led
- Hardware installation 28
- For more details
- Clr_cmos clearing cmos jumper
- Usethisjumpertoclearthecmosvalues e g dateinformationandbiosconfigurations andreset the cmos values to factory defaults to clear the cmos values place a jumper cap on the two pins to temporarily short the two pins or use a metal object like a screwdriver to touch the two pins for a few seconds
- The number of lighted leds indicates the cpu loading the higher the cpu loading the more the numberoflightedleds toenablethephaseleddisplayfunction pleasefirstenabledynamicenergy save
- Refer to chapter 4 dynamic energy save
- Chapter 2 bios setup
- B the post screen
- A the logo screen default
- 1 startup screen
- Sample bios version e19
- Bios setup program function keys
- 2 the main menu
- Load optimized defaults
- Load fail safe defaults
- Keys for the main menu only
- Integrated peripherals
- Exit without saving
- Advanced bios features
- Standard cmos features
- Set user password
- Set supervisor password
- Save exit setup
- Power management setup
- Pc health status
- Mb intelligent tweaker m i t
- Whether the system will work stably with the overclock overvoltage settings you made is dependent onyouroverallsystemconfigurations incorrectlydoingoverclock overvoltagemayresultindam age to cpu chipset or memory and reduce the useful life of these components this page is for advanced users only and we recommend you not to alter the default settings to prevent system instability or other unexpected results inadequately altering the settings may result in system s failure to boot if this occurs clear the cmos values and reset the board to default values
- This section provides information on the bios version cpu base clock cpu frequency memory frequency total memory size cpu temperature chipset temperature vcore and memory voltage
- 33 bios setup
- 3 mb intelligent tweaker m i t
- Being installed being installed
- Allows you to alter the clock ratio for the installed cpu the adjustable range is dependent on the cpu
- Advanced frequency settings
- Advanced cpu core features
- About intel cpus unique features please visit intel s website about intel cpus unique features please visit intel s website
- This screen provides information on cpu memory frequencies parameters
- Note this item is present only when you install a cpu that supports this feature for more information
- M i t current status
- Displays the current operating cpu frequency
- Cpu frequency
- Cpu clock ratio
- Bios setup 34
- Turbo power limit watts
- Real time ratio changes in os
- Intel r turbo boost tech
- Cpu thermal monito
- Cpu multi threadin
- Cpu enhanced halt c1e
- Cpu cores enable
- Core current limit amps
- C3 c6 state suppor
- Turbo ratio 1 core 2 core 3 core 4 core
- System memory multiplier spd
- Memory frequency mhz
- Internal graphics clock
- Cpu eist functio
- Bi directional procho
- Performance enhance
- Extreme extreme lets the system operate at its best performance level
- Enables or disables memory rank interleaving enabled allows the system to simultaneously access dif ferent ranks of the memory to increase memory performance and stability auto lets the bios automati callyconfigurethissetting default auto
- Enables or disables memory channel interleaving enabled allows the system to simultaneously access different channels of the memory to increase memory performance and stability auto lets the bios au tomaticallyconfigurethissetting default auto
- Dram timing selectable spd
- Displays the memory voltage as 1 v
- Channel interleaving
- Allows the system to operate at three different performance levels
- Turbo turbo lets the system operate at its good performance level default
- Advanced memory settings
- The value displayed here is dependent on the cpu being used
- 37 bios setup
- The settings under the two items above are synchronous to those under the same items on the ad vanced frequency settings menu
- System memory multiplier spd memory frequency mhz
- Standard standard lets the system operate at its basic performance level
- Rank interleaving
- Quick and expert allows the channel interleaving rank interleaving channel a timing settings and channel b timing settings itemstobeconfigurable optionsare auto default quick expert
- Profile vtt voltage
- Profile ddr voltage
- Bios setup 38
- Options are auto default 1 15
- Options are auto default 1 12
- Channel a b timing settings
- Channel a b standard timing control
- Channel a b advanced timing control
- Cas latency time
- Options are auto default 5 15
- Options are auto default 1 63
- Options are auto default 1 40
- Options are auto default 1 31
- Options are auto default 1 255
- Options are auto default 1 16
- Mch ich
- Io latency
- Graphics dvid
- Dynamic vcore dvid
- Dram voltage
- Cpu vcore
- Command rate cmd
- Channel a b misc timing control
- Thisoptionisconfigurableonlywhen cpu vcore is set to normal the default is auto
- Advanced voltage settings
- The default is auto
- 39 bios setup
- Round trip latency
- Qpi vtt voltage
- Pch core
- Options are auto default 1 31
- Options are auto default 1 3
- Options are auto default 1 255
- Virtualization technolog
- Note this item is present only when you install a cpu that supports this feature for more information
- Miscellaneous settings
- Isochronous support
- Enables or disables intel virtualization technology virtualization enhanced by intel virtualization tech nology will allow a platform to run multiple operating systems and applications in independent partitions with virtualization one computer system can function as multiple virtual systems default enabled
- Determineswhethertoenablespecificstreamswithinthecpuandchipset default enabled
- Bios setup 40
- About intel cpus unique features please visit intel s website about intel cpus unique features please visit intel s website
- Time hh mm ss
- Ide channel 2 3 master 4 master slave
- Ide channel 0 1 master
- Date mm dd yy
- 4 standard cmos features
- Memory
- Halt on
- Password check
- Note this item is present only when you install a cpu that supports this feature for more information about intel cpus unique features please visit intel s website
- Here synchronize with the settings of the smart quickboot of smart 6 default disabled here synchronize with the settings of the smart quickboot of smart 6 default disabled
- Hard disk boot priority
- First second third boot device
- Enables or disables the quick boot function to speed up the system boot up process to shorten the wait ingtimeforenteringtheoperatingsystemandtodelivergreaterefficiencyfordailyuse thesettings
- Cd dvd boot option
- 5 advanced bios features
- 43 bios setup
- Toexitthismenuwhenfinished
- To accept options are hard disk cdrom usb fdd usb zip usb cdrom usb hdd legacy lan disabled
- System system a password is required for booting the system and for entering the bios setup
- Specifieswhetherapasswordisrequiredeverytimethesystemboots oronlywhenyouenterbios setup afterconfiguringthisitem setthepassword s underthe set supervisor user password item in the bios main menu
- Setup setup a password is only required for entering the bios setup program default
- Set this item to efi if you want to install the operating system to a hard drive larger than 2 tb make sure the operating system to be installed supports booting from a gpt partition such as windows 7 64 bit and windows server 2003 64 bit auto letsthebiosautomaticallyconfigurethissettingdepending on the hard drive you install default auto
- Quick boot
- Program program
- Onboard vga
- On chip frame buffer size
- No execute memory protec
- Limit cpuid max to
- Init display first
- Hdd s m a r t capability
- Full screen logo show
- Delay for hdd secs
- In legacy mode the sata controllers use dedicated irqs that cannot be shared with in legacy mode the sata controllers use dedicated irqs that cannot be shared with
- If you wish to install a 3rd party add in network card instead of using the onboard lan set this item to if you wish to install a 3rd party add in network card instead of using the onboard lan set this item to disabled
- If you wish to install a 3rd party add in audio card instead of using the onboard audio set this item to if you wish to install a 3rd party add in audio card instead of using the onboard audio set this item to disabled
- Enables or disables the onboard lan function default enabled
- Enables or disables the onboard audio function default auto
- Enables or disables the integrated usb controller default enabled
- Enabled enabled allows the sata controllers to operate in native ide mode
- Enable native ide mode if you wish to install operating systems that support native enable native ide mode if you wish to install operating systems that support native
- Usb storage function
- Do not support native mode do not support native mode
- Usb legacy function
- Disabled disabled will turn off all of the usb functionalities below
- Usb controllers
- Disabled disabled allows the sata controllers to operate in legacy ide mode
- Specifiestheoperatingmodeoftheintegratedsatacontrollers
- Determineswhethertodetectusbstoragedevices includingusbflashdrivesandusbharddrives during the post default enabled
- Sata port0 1 native mode intel h61 chipset
- Azalia codec
- Other device set this option to other device set this option to disabled if you wish to install operating systems that
- Allows usb keyboard to be used in ms dos default enabled
- Onboard h a lan
- 6 integrated peripherals
- 45 bios setup
- Mode default mode default
- Smart lan
- Onboard usb 3 controller etron ej168 usb controller
- Onboard serial port 1
- Onboard lan boot rom
- Marvell 88se917
- Gsata3 ctrl mode
- Gsata3 controller
- Chip gsata3_4 and gsata3_5 connectors
- S1 pos s1 pos enables the system to enter the acpi s1 power on suspend sleep state
- Power on by ring
- Pme event wake up
- Note supported on windows 7 vista operating system only
- Its working state exactly where it was left off its working state exactly where it was left off
- Instant off instant off press the power button and then the system will be turned off instantly default
- In s3 sleep state the system appears to be off and consumes less power than in in s3 sleep state the system appears to be off and consumes less power than in
- In s1 sleep state the system appears suspended and stays in a low power mode in s1 sleep state the system appears suspended and stays in a low power mode
- Delay 4 sec delay 4 sec press and hold the power button for 4 seconds to turn off the system if the power
- Configuresthewaytoturnoffthecomputerinms dosmodeusingthepowerbutton
- Button is pressed for less than 4 seconds the system will enter suspend mode button is pressed for less than 4 seconds the system will enter suspend mode
- The system can be resumed at any time the system can be resumed at any time
- Bios setup 48
- The s1 state when signaled by a wake up device or event the system resumes to the s1 state when signaled by a wake up device or event the system resumes to
- Allows the system to be awakened from an acpi sleep state by a wake up signal from a pci or pcie de vice note to use this function you need an atx power supply providing at least 1a on the 5vsb lead default enabled
- Specifiestheacpisleepstatewhenthesystementerssuspend
- Allows the system to be awakened from an acpi sleep state by a wake up signal from a modem that supports wake up function default enabled
- Soft off by pwr bttn
- Acpi suspend type
- S3 str s3 str enables the system to enter the acpi s3 suspend to ram sleep state default
- 7 power management setup
- Resume by alarm
- Power on by mouse
- Power on by keyboard
- Kb power on password
- Hpet suppor
- Hpet mod
- Erp support
- Ac back function
- Bios setup 50
- Allows the system to emit warning sound if the cpu system fan is not connected or fails check the fan condition or fan connection when this occurs default disabled
- 8 pc health status
- Sets the warning threshold for cpu temperature when cpu temperature exceeds the threshold bios will emit warning sound options are disabled default 6
- Reset case open status
- Keeps or clears the record of previous chassis intrusion status enabled clears the record of previous chassis intrusion status and the case opened fieldwillshow no atnextboot default disabled
- Displays the detection status of the chassis intrusion detection device attached to the motherboard ci header ifthesystemchassiscoverisremoved thisfieldwillshow yes otherwiseitwillshow no to clear the chassis intrusion status record set reset case open status to enabled save the settings to the cmos and then restart your system
- Displays the current system voltages
- Displays current system cpu temperature
- Displays current cpu system fan speed
- Current voltage v vcore ddr15v 12v vtt
- Current system cpu temperature
- Current cpu system fan speed rpm
- Cpu warning temperature
- Cpu system fan fail warning
- Case opened
- Slope pwm
- Cpu smart fan mode
- Cpu smart fan control
- Key to load the safest bios default settings in case system instability occurs you may try to load fail safe defaults which are the safest and most stable bios settings for the motherboard
- Key to load the optimal bios default settings the bios defaults settings help the system to operate in optimum state always load the optimized defaults after updating the bios or after clearing the cmos values
- Bios setup 52
- 9 load fail safe defaults
- 10 load optimized defaults
- When the when the password check item is set to system you must enter the supervisor password or user password at system startup to continue system boot in bios setup you must enter the supervisor password if you wish to make changes to bios settings the user password only allows you to view the bios settings but not to make changes
- When the when the password check item is set to system you must enter the supervisor password or user password at system startup and when entering bios setup
- When a system password is set and the when a system password is set and the password check item in advanced bios features is set to setup you must enter the supervisor password for entering bios setup and making bios changes
- User password
- The bios setup program allows you to specify two separate passwords
- Supervisor password
- Again the message password disabled will appear indicating the password has been can celled
- 53 bios setup
- 11 set supervisor user password
- 13 exit without saving
- 12 save exit setup
- To return to the bios setup main menu
- Bios setup 54
- Chapter 3 drivers installation
- 1 installing chipset drivers
- 3 technical manuals
- 2 application software
- 5 system
- 4 contact
- 7 new utilities
- 6 download center
- System requirements
- Installation and configuration
- Chapter 4 unique features
- Before you begin
- 1 xpress recovery2
- 2 1 updating the bios with the q flash utility
- A before you begin
- 2 bios update utilities
- Whenupdatingthebios choosethelocationwherethebiosfileissaved thefollowingprocedureas sumesthatyousavethebiosfiletoausbflashdrive
- To begin the bios update the monitor will display the update process
- The save main bios to drive optionallowsyoutosavethecurrentbiosfile q flashonlysupportsusbflashdriveorharddrivesusingfat32 16 12filesystem ifthebiosupdatefileissavedtoaharddriveinraid ahcimodeoraharddriveattachedto
- Step 3 when the update process is complete press any key to return to the main menu
- Make sure the bios update file matches your motherboard model
- Key during the post to access q flash
- Do not turn off or restart the system when the system is reading updating the bios do not remove the usb flash drive or hard drive when the system is updating the bios
- B updating the bios
- 63 unique features
- Unique features 64
- To save settings to cmos and exit bios setup the proce dure is complete after the system restarts
- To load bios defaults system will re detect all peripheral devices after a bios update so we recommend that you reload bios defaults
- To load bios defaults
- To exit q flash and reboot the system as the system boots you should see the new bios version is present on the post screen
- C after updating the bios
- B using bios
- A before you begin
- 2 2 updating the bios with the bios utility
- Unique features 66
- The easytune 6 interface
- Tabs information
- Tab function
- Gigabyte seasytune6isasimpleandeasy to useinterfacethatallowsuserstofine tunetheirsystem settings or do overclock overvoltage in windows environment the user friendly easytune 6 interface also includes tabbed pages for cpu and memory information letting users read their system related information without the need to install additional software
- 3 easytune 6
- The dynamic energy save
- Meter mode button information table
- Interface a meter mode
- 4 dynamic energy saver 2
- 4 dynamic energy save
- B total mode
- Total mode button information table
- C stealth mode
- Options descriptions
- Directions for using q share
- 5 q share
- Smart quickboot
- Smart quickboost
- 6 smart 6
- 6 smart
- Smart recovery 2
- Smart dualbios
- Smart timelock
- Smart recorder
- Configuring other bluetooth settings
- Auto green is an easy to use tool that provides users with simple options to enable system power savings via a bluetooth cell phone when the phone is out of the range of the computer s bluetooth receiver the sys temwillenterthespecifiedpowersavingmode
- 7 auto green
- Unique features 74
- The configuration dialog box
- Selecting a system energy saving mode
- Configuring the bluetooth cell phone key
- Is an easy to use overclocking utility designed for system overclock ing via virtually any internet connected device such as a smart phone iphone note book pc etc by simply connecting to an internet browser via lan wireless lan or
- Cloud o
- Bluetoot
- B directions for us
- And logging in to the cloud oc server you can easily access three major functions of cloud oc including tuner system tweaking system info system monitoring and control system status control
- A launching cloud oc
- 8 cloud oc
- 75 unique features
- Before you begin
- A installing sata hard drive s in your computer
- 1 configuring sata hard drive s
- 1 1 configuring marvell 88se9172 sata controller
- To configure sata hard drive s follow the steps below
- Chapter 5 appendix
- To enter bios setup during the post in bios setup go to in tegrated peripherals to enable raid set gsata3 controller to enabled and set gsata3 ctrl mode to raid
- The bios setup menus described in this section may differ from the exact settings for your moth erboard the actual bios setup menu options you will see shall depend on the motherboard you have and the bios version
- Step 2 save changes and exit bios setup
- Makesuretoconfigurethesatacontrollermodecorrectlyinsystembiossetup
- Figure 1
- B configuring sata controller mode in bios setup
- Appendix 78
- To en ter the raid setup utility
- On the main screen of the raid setup utility figure 3 use the left or right arrow key to move through tabs
- Figure 3
- Figure 2
- Entertheraidbiossetuputilitytoconfigurearaidarray skipthisstepandproceedtotheinstallationof windowsoperatingsystemforanon raidconfiguration
- C configuring a raid array in raid bios
- 79 appendix
- On the create vd item
- On next
- Figure 5
- Figure 4
- Appendix 80
- Tocancel figure7
- To display options set the required items in sequence and press the down arrow key to proceed to the next item sequence 1 raid level select a raid level options include raid 0 stripe and raid 1 mirror 2 stripe size select the stripe block size options include 32 kb 64 kb and 128 kb 3 quick init select whether to quickly erase old data on the hard drives when creating the array 4 cache mode select write back or write through cache 5 vd name enter an array name with 1 10 letters letters cannot be special characters
- To begin creating the array
- Figure 7
- Figure 6
- 81 appendix
- To clear the mbr or press other keys to ignore
- Figure 9
- Figure 8
- Delete the raid array
- Appendix 82
- When completed the raid tab will display the new array figure 8
- Toconfirm now you can proceed to install the operating system
- Toconfirm figure9
- A installing windows 7 vista
- 1 2 installing the sata raid ahci driver and operating system
- B installing windows xp
- Toconfirm thenewharddriveisnowsetasa spare drive
- To enter the raid setup utility on the main screen
- Step 2
- Rebuilding is the process of restoring data to a hard drive from other drives in the array rebuilding applies only to fault tolerant arrays such as raid 1 array the procedures below assume a new drive is added to re place a failed drive to rebuild a raid 1 array note the new drive must have equal or greater capacity than the old one
- On spare management
- For the marvell 88se9172 turn off your computer and replace the failed hard drive with a new one restart your computer to enable an automatic rebuild in the operating system you have to set the new hard drive as a spare drive in the raid setuputilityfirst
- C rebuilding an array
- 87 appendix
- 2 configuring audio input and output
- 2 1 configuring 2 4 5 7 channel audio
- A configuring speakers
- D muting the back panel audio for hd audio only
- C activating an ac 97 front panel audio module
- B configuring sound effect
- 2 3 configuring microphone recording
- 2 2 configuring s pdif out
- Enabling stereo mix
- B playing the recorded sound
- A recording sound
- 2 4 using the sound recorder
- To read more faqs for your motherboard please go to the support downloads faq page on gigabyte s website
- 95 appendix
- 3 troubleshooting
- 3 1 frequently asked questions
- If you encounter any troubles during system startup follow the troubleshooting procedure below to solve the problem
- Appendix 96
- 3 2 troubleshooting procedure
- If the procedure above is unable to solve your problem contact the place of purchase or local deal er for help or go to the support downloads technical support page to submit your question our customer service staff will reply you as soon as possible
- 97 appendix
- Contact us
- 103 appendix
- To submit a technical or non technical sales market ing question please link to http ggts gigabyte com tw then select your language to enter the system
- Gigabyte global service system
- Appendix 104
Похожие устройства
-
Gigabyte B760M D3H DDR4Инструкция пользователя -
Gigabyte GA-880GM-D2HИнструкция по работе -
Gigabyte Z890 EAGLEЭксплуатационная инструкция -
Gigabyte Z890 EAGLE WIFI7Инструкция по применению
-
Gigabyte H610M S2HРуководство по использованию -
Gigabyte Z790 AORUS MASTER XРуководство по работе с устройством -
Gigabyte B660M GAMINGИнструкция пользователя -
Gigabyte B550M DS3H ACИнструкция по работе -
Gigabyte GA-Q87TNРуководство по настройке -
Gigabyte GA-H87TNИнструкция по работе
-
Gigabyte GA-B85TNРуководство пользователя
-
Gigabyte GA-H81TNИнструкция по применению
Изучите настройки BIOS, включая управление напряжением процессора и таймингами памяти. Узнайте, как оптимизировать производительность вашего компьютера.
