Gigabyte GA-HA65M-D2H-B3 (REV. 1.0) — как включить Stereo Mix для записи звука на компьютере [93/104]
Превью страниц
Страница 93 /
104
![Gigabyte GA-HA65M-D2H-B3 (REV. 1.0) [93/104] Enabling stereo mix](/views2/1115409/page93/bg5d.png)
- 93 - Appendix
Step 1:
Locate the icon in the notification area and right-
click on this icon. Select Recording Devices.
Step 2:
On the Recording tab, right-click on an empty space
and select Show Disabled Devices.
* Enabling Stereo Mix
If the HD Audio Manager does not display the recording device you wish to use, refer to the steps below. The
following steps explain how to enable Stereo Mix (which may be needed when you want to record sound from
your computer).
Step 3:
When the Stereo Mix item appears, right-click on this
item and select Enable. Then set it as the default de-
vice.
