Hardware Installation - 22 -

ATX_12V:

ATX:

1/2) ATX_12V/ATX (2x2 12V Power Connector and 2x12 Main Power Connector)

With the use of the power connector, the power supply can supply enough stable power to all the com-

ponentsonthemotherboard.Beforeconnectingthepowerconnector,rstmakesurethepowersupply

is turned off and all devices are properly installed. The power connector possesses a foolproof design.

Connect the power supply cable to the power connector in the correct orientation. The 12V power con-

nector mainly supplies power to the CPU. If the 12V power connector is not connected, the computer will

not start.

To meet expansion requirements, it is recommended that a power supply that can withstand high

power consumption be used (500W or greater). If a power supply is used that does not provide

the required power, the result can lead to an unstable or unbootable system.

DEBUG

PORT

G.QBOFM

131

2412

ATX

ATX_12V

Pin No. Denition

1 GND

2 GND

3 +12V

4 +12V

Pin No. Denition Pin No. Denition

1 3.3V 13 3.3V

2 3.3V 14 -12V

3 GND 15 GND

4 +5V 16 PS_ON (soft On/Off)

5 GND 17 GND

6 +5V 18 GND

7 GND 19 GND

8 Power Good 20 -5V

9 5VSB (stand by +5V) 21 +5V

10 +12V 22 +5V

11 +12V (Only for 2x12-pin ATX) 23 +5V (Only for 2x12-pin ATX)

12 3.3V (Only for 2x12-pin ATX) 24 GND (Only for 2x12-pin ATX)
