- 91 - Appendix

5-2-2 Conguring S/PDIF Out

Enter the Digital OutputscreentocongurefurthersettingsifyouusetheinternalS/PDIFOutconnector

(SPDIF_O) for digital audio output.

5-2-3 Conguring Microphone Recording

Step 2:

Connect your microphone to the Mic in jack (pink) on

the back panel or the Mic in jack (pink) on the front

panel.Thencongurethejackformicrophonefunction-

ality.

Note: The microphone functions on the front panel and

back panel cannot be used at the same time.

Step 1:

After installing the audio driver, the HD Audio Manager

icon willappearinthenoticationarea.Double-click

the icon to access the HD Audio Manager.
