![Tascam CD-01 U [14/28] Menu operation](/views2/1011765/page14/bge.png)
14 TASCAM CD-01U/CD-01U Pro
5 - Menu operation
The various settings and editing operations possible
with the CD-01U/CD-01U Pro are performed through
menu options shown on the display. Among the many
menu setting options, some may be made directly using
the keys on the remote control.
No. Menu Function Parameter Manual reference Page
Underlined values are fac-
tory default settings
01 KEY-0 Key Original ON, OFF Key Original 21
02 BLOCK Eject Block ON, OFF Eject Block 23
03 REPEAT Repeat Playback OFF
, ON, A-B Repeat Playback 19
A-B Repeat Playback 19
04 PROG Program rogram operation Program Playback 21
05 FADE Fade In/Out OFF, 0.5-10.0 Fade In/Out 22
06 RELAY Relay Playback OFF
, ON, FDR Relay Play 21
Fader/Event Start 23
07 TIMER Power on Play ON, OFF Power on play 20
08 MONO Mono Output ON, OFF
Output in Mono 20
09 RESUME Resume ON, OFF
Resume 18
10 EOM EOM Time OFF, 5, 10, 15, 20, EOM 23
25, 30, 35 sec.
11 INCR Incremental Play ON, OFF
Incremental Play 19
12 PITCH Pitch Step 0.1, 0.5, 1.0 % Pitch Control 20
13 RS232C Baud rate setting 96, 192, 384
14 F-PRE Factory Preset (SURE) Restoring the default setting 24
15 U-DATA User Data ON
, OFF ÆÆ
ÆÆ When digital output signal from the AES/EBU terminal is not received correctly on the other digital equipment , set
the user data to OFF then try again.
Operation basics
1 Press the PITCH knob on the front panel when
SHIFT indicator is lit or press the MENU key on the
remote control.
2 Use the PITCH knob on the front panel, or
PREV/NEXT keys or number keys on the remote
control to select the menu item.
3 Press the PITCH knob on the front panel or ENTER
key on the remote control.
4 Use the PITCH knob on the front panel or
PREV/NEXT keys on the remote control to select the
setting value.
5 Press the PITCH knob on the front panel or ENTER
key on the remote control.
Pressing the DISPLAY key on either the front panel or
the remote control exits the menu mode.
Menu No. Menu Parameter
