![Tascam CD-01U PRO [22/28] Advanced operations](/img/pdf.png)
Tascam CD-01U PRO [22/28] Advanced operations
![Tascam CD-01UPro [22/28] Advanced operations](/views2/1011765/page22/bg16.png)
When this function is on and CD playback begins, the
song fades in. When playback is finished, the song
fades out.
The length of the fade in/out to/from the normal level
can be set between 0.5 and 10 seconds in 0.5 second
increments (Default setting: OFF).
1 To set the fade operation, enter the fade menu (menu
number 05 FADE).
2 Press the PITCH knob on the front panel or ENTER
key on the remote control to enter the fade in time
setting.
3 Set the Fade in time using with the PITCH knob on
the front panel or PREV/NEXT keys on the remote
control.
4 Press the PITCH knob on the front panel or ENTER
key on the remote control to set the fade in time and
enter the fade out time setting.
5 Set the Fade out time using with the PITCH knob on
the front panel or PREV/NEXT keys on the remote
control.
6 Press the PITCH knob on the front panel or ENTER
key on the remote control to set the fade out time
and exit the menu.
7 - Advanced operations
1 Enter the program mode.
2 Use the SEARCH keys to select the track for deletion.
Also using the PITCH knob on the front panel to
select the track for deletion. The track number will be
shown in the display.
3 Pressing the DISPLAY key and SEARCH ∆ key
simultaneously on the front panel or pressing the
A.CUE/DEL key deletes the selected track.
4 Pressing the PITCH knob on the front panel or PGM
key on the remote control exits the program mode.
Fade-in and fade-out
Relay Play
Deleting a programmed track
When the disc in the first unit in a chain plays to the
end, the disc in the next unit in the chain will start.
Make all connections with power off.
1. Check to see that all the CD-01Us are turned off.
2. Refer to the diagrams, and connect the first CD-
01U's RELAY OUT to the second CD-01U's RELAY
IN, the second CD-01U's RELAY OUT to the third
CD-01U's RELAY IN, and so on. Finally, connect the
last CD-01U's RELAY OUT to the first CD-01U's
RELAY IN.
3. Switch on power to all the CD-01Us.
4. To activate the relay play function, set the relay play
menu (menu number 06 RELAY) to on for all the units
in the chain.
RELAY IN
RELAY IN
RELAY OUT
RELAY OUT
RELAY IN
RELAY IN RELAY IN
RELAY OUT
RELAY OUT
22 TASCAM CD-01U/CD-01UPro
