TASCAM CD-01U/CD-01UPro 23
Time display switching
Fader start/Event start
End of track warning (EOM)
Eject block
Fader start/stop
7 - Advanced operations
During audio CD playback (or playback standby), when
the DISPLAY key on either the front panel or the
remote control is pressed, the time display will switch
through several modes in the following order.
Elapsed track time (no display light indication)
Remaining track time (REMAIN is lit in the display)
Remaining disc time (T. and REMAIN are lit in the display)
When stopped, the total recording time is shown, regard-
less of the status of the TOTAL and REMAIN indicators.
When playing an MP3 disc, elapsed track time is always
displayed, and the DISPLAY key does not operate.
Even when the power is turned off, the time display
mode setting is retained.
When in program play mode, remaining total program
time (when T.REMAIN is lit) and total program time
(when stopped) are shown.
When eject block is on, the EJECT key cannot be used
when a disc is being played back or paused.
Use the eject block menu (menu number 02 BLOCK) to
turn this function on and off.
When nearing the end of a track, a warning indication is
shown on the display.
The number of seconds before the track end that the
warning is displayed can be set beforehand, so that
when playback reaches that point, the two colons will
begin flashing on the display.
To set the warning display time, use the EOM menu
(menu number 10 EOM).
EOM time can be set from OFF, 5, 10, 15, 20, 25, 30
(default), and 35.
This function is not supported for MP3 playback.
Connect the RELAY IN jack (mini jack) on the rear panel
and fader start terminal on the external device which
supports the fader start function.
The relay play menu (menu number 06 RELAY) should
be set to FDR.
For CD-01U Pro only, connect the CONTROL I/O
(PRALLEL) terminal on the rear panel and fader start
terminal on the external device.
See more detailes for the CONTROL I/O terminal in the
secsion External parallel control on page 24.
START
FADER STRAT/STOP
STOP
CONTROL I/O
PIN8 GND
PIN11
STOP
START
SLEEVE
SLEEVETIP TIP
RELAY IN
