Tc Electronic TRIPLE-C STEREO [7/31] Front panel
![Tc Electronic TRIPLE-C STEREO [7/31] Front panel](/views2/1011842/page7/bg7.png)
7
FRONT PANEL
LOOK AHEAD key
When in Multi-band mode the
Look Ahead delay (3ms) can be
activated allowing even more pre-
cise processing.
THRESHOLD knob
Multi-band mode:
Sets the Mid
band Threshold value. The Lo/Hi
bands are slaved accordingly.
Full-range mode:
Sets the
Threshold value.
Envelope mode: Sets the
Threshold of the Envelope.
RATIO knob
Multi-band mode:
Sets the Mid
band Ratio value. The Lo/Hi
bands are slaved accordingly.
Full-range mode:
Sets the
compression Ratio.
Envelope mode:
No function.
ATTACK knob
Multi-band mode: Sets the Mid
band Attack value. The Lo/Hi
bands are slaved accordingly.
Full-range mode:
Sets the Attack
time.
Envelope mode:
Sets the Attack
time of the gain added to the
start-up of the source.
BYPASS key
Bypasses all processing parameters
but not the System settings found in
the I/O menu. When the key LED is
lit the TRIPLE•C is bypassed.
LEVEL knob
Sets the overall Make Up gain
through the TRIPLE•C. This is used
to compensate for gain loss in the
Compressor. The absolute gain
through the TRIPLE•C is displayed
in the LCD by the fixed LED in the
gain meter. Range: +/- 18dB.
MENU key
Push MENU and use the VALUE
SET wheel to select menu.
PARAMETER wheel
Scrolls between parameters.
VALUE SET/ENTER wheel
Is used to change values.
When pushed, actions such as
Recall, Store etc. are approved.
RELEASE knob
Multi-band mode:
Sets the Mid
band Release time. The Lo/Hi
bands are slaved accordingly.
Full-range mode:
Sets the
Release time.
Envelope mode:
Sets the
Release time of the gain added to
the ring-out of the source.
ENVELOPE MODE key
Activates/deactivates the
Envelope mode.
LO-BAND knob
Multi-band mode:
Adjusts the Output level of the
processed Lo-Frequency band.
Full-range mode:
No function
Envelope mode: Attack Gain.
HI-BAND knob
Multi-band mode:
Adjusts the Output level of the
processed Hi-Frequency band.
Full-range mode:
No function
Envelope mode: Release Gain.
