8
REAR PANEL
Balanced
Jack
Analog
Inputs
Balanced
Jack
Analog
Outputs
Pedal Input
for Bypass
MIDI
In, Out, Thru
Digital
S/PDIF
Input/
Output
Sleeve - Pin 1 (Ground)
Tip - Pin 2 (Hot)
Ring - Pin 3 (Cold)
Sleeve - Pin 1 (Ground)
Tip - Pin 2 (Hot)
Sleeve - Pin 3 (Cold)
Jack (unbalanced) - XLR
Jack (balanced) - XLR
TIP
RING
GND
TIP
GND
MIDI Cable
DIN CONNECTOR
5POLE - MALE
45 degrees
DIN CONNECTOR
5POLE - MALE
45 degrees
max. 10m
SHIELDED CABLE (3 or 5 wires + screen)
Serial no.Power
Input
Balanced
Jack
Analog
Inputs
Balanced
Jack
Analog
Outputs
Pedal Input
for Bypass
MIDI
In, Out, Thru
Digital
S/PDIF
Input/
Output
Serial no.Power
Input
Single Version
