Kranzle 1+1 [4/20] First operation
![Kranzle 1+1 [4/20] First operation](/views2/1119861/page4/bg4.png)
4
First operation
Assembly
Attach handlebar
For reasons of packaging, handlebar
and side boom arm, to include broom
and Vee belt are not assembled. After
unpacking the KRÄNZLE 1+1, first
assemble the handlebar and the side
broom next.
Bolt handlebar to both sides of the
housing, use the wing bolts (A/1)
Note: The handlebar can be mounted
in two positions, as suitable for the
operator´s tallness.
For short people: Install the handlebar
with handle rod bent to downside.
For average and bigger tallness: Install
the handlebar with handle rod bent to the
top end.
