Operating the KRÄNZLE 1+1

All controls are identified by easy-to-understand symbols which will help you to

get familiar with the machine.

The KRÄNZLE 1+1 uses two brooms. The dish-type side broom feeds the

matter swept to the main broom. The main broom is rotating against the direction

of travel of the machine and throws the dirt into the dirt hopper located at the

forward end.

Both brooms are driven by the machine wheels.

A jackwheel will guarantee uniform ground clearance and perfect sweeping.

The broom housing uses rubber seals all around to seal it against the floor

surface. At the forward end, the broom housing is closed by the dirt hopper, at the

rear end a large rubber lip is assembled.

If any part of the floor shall be omitted (smeared floor or transport), just lift both

brooms from the floor by depressing the handlebar. Steps and stairs are easily

overcome by the KRÄNZLE 1+1.

The large wheels extend beyond the rear end of the machine. This means that

all usual obstacles are overcome by pulling the machine “uphill” or pushing it

“downhill”. The handlebar is folding to ease transportation or storage of the

KRÄNZLE 1+1.

For folding, loosen both wingbolts a few turns, expand the handlebar structure

and fold forward.
