Emptying the dirt hopper
Insert the dirt hopper
Handwheel to adjust side broom
The broom may touch the floor with
the forward 2/3 of its circumference
only so that it can feed the rubbish
to the forward end of the main
broom and not sweep it around
only. The present working level of
the side broom is kept constant as
soon as the knurled nut (checknut)
is tightened in position.
To lift the dirt hopper, just use the
handle provided.
Locate the hopper on the forward
frame as shown, and slue down.
Note: Do not place the dirt hopper
flat on ground to avoid damage to
the rubber lip. Use the four feet for
storing the detached hopper.
