00.5
12 Engine electrics
Starter motor to engine 20
Starter cover to housing 7
Positive lead to starter motor 10
Alternator to cover mount 20
Tensioning and retaining strap at alternator 20
Spacer at alternator 20
Positive lead to alternator 15
Belt pulley at alternator 50
Belt pulley to crankshaft 50
Poly-V belt preload 8
Spark plug 20
Ignition coil holder to frame 9
13 Fuel preparation and control
Oil temperature sensor to engine block 25
Air temperature sensor to air cleaner cover 10
16 Fuel tank and lines
Fuel tank to rear frame 10
18 Exhaust system
Manifold to cylinder head 24
Clip on muffler 55 (apply Never Seez to clip contact surface)
Oxygen sensor (lambda probe) to muffler 45 (apply Never Seez to thread)
21 Clutch
Clutch housing Joint torque
40 (oil screw threads lightly)
Additional wrench
angle 32°
Housing cover 12
Slave cylinder to gearbox 9
Clutch line to handlebar fitting 18
Model R 850/1200 C
Connection Nm
