00.6
23 Transmission
Oil filler plug 23
Oil drain plug 55
Gearbox to engine block 22
Gear shift pedal to rear frame 41
Selector lever to selector shaft 9
Gearbox cover to gearbox housing 9
31 Front fork
Fixed tube to fork bridge 35 (free from oil and grease)
Slider tube bridge to slider tube 22 (clean thread + Loctite 243)
Quick-release axle clamp screws 20
Threaded journal to frame 130 (clean thread + Loctite 243)
Ball joint to fork slider bridge 230 (apply light coat of Never Seez to thread)
Leading link to ball joint 130 (clean thread + Loctite 2701)
Leading link to engine right 73
Screw cap at leading link left 42 (apply light coat of Never Seez to thread)
Spring strut to frame
40
Spring strut to leading link
40
32 Steering
Handlebar at fork bridge 21 (apply light coat of Never Seez to thread)
Twistgrip to handlebar 8
33 Rear wheel drive
Oil filler plug 23
Oil drain plug 23
Threaded ring 118 (Hylomar SQ 32 M)
Hexagon nut, input bevel gear
200 (clean thread + Loctite 2701)
Cover at rear-wheel drive housing 35
Rear-wheel drive to swinging arm 24
Swinging arm bearing journal to rear frame right 9
Swinging arm bearing journal to rear frame left 7 (clean thread + Loctite 2701)
Locknut at swinging arm bearing journal 160
Suspension strut to rear frame 50
Suspension strut to rear swinging arm 50
Model R 850/1200 C
Connection Nm
