BATTERY
INSPECTION
Acid
2
-
35
BATTERY INSPECTION
fluid
level
1.
Inspect:
Battery fluid level low
Fill.
Fluid level should be between upper and
lower
level
marks.
Upper level
Lower level
Refill with distilled water only; tap water
contains minerals harmful to
a
battery.
Battery electrolyte
is
dangerous;
it
contains
sulfuric acid and therefore
is
poisonous and
highly caustic.
Always follow these preventivemeasures:
bodily contact with electrolyte
as
it
can cause severe burns or permanent eye injury.
working near batteries.
Antidote (EXTERNAL):
-
Flush with water.
-
Flush with water for
15
minutes and
Antidote (INTERNAL):
large quantities of water or milk follow
with milk
of
magnesia beaten
egg,
or vegetable
oil.
Get
immediate medical attention.
Batteries also generate explosive hydrogen
gas,
therefore you should always follow
these
preventive measures:
batteries in
a
well
-
ventilated area.
Keep batteries away f r o m fire, sparks, or open
flames
welding equipment, lighted
cigarettes,
etc.)
NOT SMOKE when charging or handling
batteries.
KEEP BATTE RIES AND ELECTROLYTE
OUT
OF REACH OF CHILDREN.
protective eye gear when handling or
get
immediate medical attention.
