ELECTRIC STARTING SYSTEM
I
I
STARTING CIRCUIT CUT
-
OFF SYSTEM
A
starting circuit cut
-
off system
is
employed,
and operates
as
follows:
Starting Circuit Operation
The starting circuit on this model consist of
the starter motor, starter relay, and the relay
unit (starting circuit cut
-
off relay). I f the engine
stop switch and the main switch are both on,
the starter motor can operate only if:
The transmission
is
in neutral (the neutral
switch
is
on).
or
if
The clutch lever
is
pulled to the handlebar
(the clutch switch
is
on) and the sidestand
is
up (the sidestand switch
is
on.)
The starting circuit cut
-
off relay prevents the
starter from operating when neither of these
conditions has been met. I n this instance, the
starting circuit cut
-
off relay
is
off
so
current
cannot reach the starter motor.
When one of both of the above conditons
have been met, however, the starting circuit
cut
-
off relay
is
on, and the engine can be started
by pressing the starter switch.
WHEN THE TRANSMISSION
IS
IN
NEURTAL
WHEN THE SIDESTAND
IS
UP AN D
THE CLUTCH LEVER
IS
PULLED IN
WHEN THE ENGINE
IS
RUNNING
Battery
Starter motor
Starter relay
Starting circuit cut
-
off relay
Starter switch
Neutral switch
Clutch switch
Sidestand relay
To
V
-
boost
valve
control unit
To
main switch
To
engine stop switch
TO
ignitor unit
7 Sidestand switch
7
-
9
