INSPECTION AND REPAIR
the bearings, crank pins and bear
-
ing portions of the connecting rods.
the upper half of the bearing into
the connecting rod and lower half of the
bearing into the connecting rod cap.
NOTE:
Align the projection of the bearing with
the
notch of the cap and connecting
rod.
a
piece of Plastigauge® on the crank
the connecting rod halves.
pin.
NOTE:
Do
not move the connecting rod or crank
-
shaft until the oil clearance measurement
has been completed.
Apply molybdenum disulfide grease
to
the bolts, threads and nut seats.
Make sure the "Y" marks on the connect
-
ing rods face the
left
side of the crank
-
shaft.
Make sure
that
the letters on both compo
-
nents align to from
a
perfect character.
the nuts.
(3.6
m kg,
25
I
Tighten to
full
torque specificationwithout
pausing. Apply continuous torque between
3.0
and
3.8
Once you reach
3.0
DO
NOT STOP TIGHTENING until final
torque is reached. If tightening is inter
-
rupted between
3.0
and
3.8
loosen
nut to lessthan
3.0
and start again.
Remove
the
connecting rods and bear
-
ings.
Measure the compressed Plastigauge®
width
on each crank pin.
If oil clearance is out of specification,
select
a
replacement bearing.
-9-
