INSPECTION AND REPAIR
ENGINE OVERHAUL
INSPECTION AND REPAIR
CRANKSHAFT AND CONNECTING
ROD
1.Measure:
Runout (crankshaft)
Out
of
specification Replace.
Runout:
Less than
0.03
mm
(0.0012
in)
2.1
nspect:
Main journal surfaces
Crank pin surfaces
Bearing surfaces
Wear/Scratches
Replace.
3.
Measure:
Oil clearance (main journal)
Out of specification
Replace bearing.
0.020 ~
0.038
mm
(0.0008 ~
0.0015
in)
Measurement steps:
Do not interchange the bearings and con
-
necting rod. They must be installed in their
original positions, or the correct oil clear
-
ance may not be obtained causing engine
damage.
the bearings, main journals
and
bearing portions of the crankcase.
the crankcase (upper) on a bench
in
an
upside down position.
the
upper
half
of
the
bearings
and
the crankshaft into the crankcase (upper).
Align the projection of the bearing with the
notch
in
the crankcase.
N
O
TE
:
-7-
