Konica Minolta bizhub 163f [127/340] Ldap server address

Network settings

NC-503 5-47

6 Type in the IP address or host name for the LDAP server.

– The host name can contain a maximum of 64 characters.

– To specify a host name for the LDAP server, the DNS setting must

be specified.

– For the IP address or host name of the LDAP server, consult with

the network administrator.

– If the setting was incorrectly entered, press the [Clear/Stop] key to

erase it, and then type it in correctly.

7 Press the [OK] key.

After the message "ACCEPTED" appears, the "LDAP SETTING" menu

appears again.

LDAP SERVER ADDRESS
