Konica Minolta bizhub 163f [179/340] Basic transmission

Performing a scan to e-mail operation

NC-503 7-3

7 Performing a scan to e-mail operation

This chapter provides descriptions of the procedures for sending scan data

as e-mail messages.

7.1 Basic transmission

Reminder

With the Scan to E-mail operation, documents are sent through a mail

server. In addition, as soon as transmission with the server is finished

correctly, the transmission is considered complete. In order to perform

this operation, the IP address, SMTP server address and e-mail

addresses must be specified in advance.
