MAIN CONTROL PANEL 6 MAIN CONTROL PANEL Manual Exposure Setting Knob Exposure Mode Select Key M Zoom Memory Input Key ri 0 Print Key rij Clear Stop Key L Copy Quantity Key ls 0 Copy Quantity Key tOs 0 Magnification Select Key 0 Magnification Compensation Key Up 0 Magnification Compensation Key Down 0 Color Select Key ri Paper Port Select Key 10
