Can-Am Spyder RT SE5 2010 [22/39] Engine oil
![Can-Am Spyder RT SE5 2010 [22/39] Engine oil](/views2/1012801/page22/bg16.png)
FLUIDS
FUEL OCTANE RAT
ING
INSIDE NORTH AMERICA
Recommended Minimum
91
(RON + MON)/2)
87
(RON + MON )/2 )
Use premium unleaded fuel for optimum engine
performa nce.
FUEL OCTANE R
ATING
OUTSIDE NORTH AMERICA
Recommended Minimum
95 RON 92 RON
Use premium unleaded fuel for optimum engine
performa nce.
WARNING
Never top off the fuel tank before placing
the vehicle in a warm area. As temperature
increases, fuel expands and may overflow.
Fuel is flammable and explosive under cer-
tain conditions. Always wipe off any fuel or
oil spillage from the vehicle.
NOTICE
Other fuel can degrade vehicle per-
formance and damage critical parts in the fuel
system and engine.
Engine Oil
NOTICE
The proce
dures for checking the
Spyder r
oadster oil level and replacing oil are
differe
nt from most of the motor vehicles to-
day. Pro
perly follow instructions provided in
this sec
tion.
Recommended Engine Oil
NOTE: For SM5 models, the same oil lubricates
the engine, the gearbox and the clutch.
NOTE: Fo
r SE5 models, the same oil lubricates the
engine,
the gearbox, the clutch and the HCM (hy-
drauli
c control module).
Use
XPS SYNTHETIC BLEND OIL (SUMMER GRADE)
(P/N 293 600 121)
.
If not available, use a 5W 40 semi-synthetic (mini-
mum) or synthetic motorcycle oil meeting the re-
quirements for API service SL, SJ, SH or SG clas-
sification. Always check the API service label on
the oil container.
NOTICE
To avoid damaging the clutch, do not
use a motor oil meeting the API service SM or
ILSAC GF-4 classification. Clutch slippage will
occur. Motorcycle oils designed for use with a
wet-clutch are the best alternative.
Engine Oil Level Verification
WARNING
Before starti
ng vehicle ensure vehicle in a
well ventilat
ed area or is outside. Smoke will
come from the
engine for 10 minutes as the
anti corrosi
on coating on the exhaust system
and engine bu
rns off.
NOTICE
For an accur
ate oil level reading, it is
necessary t
o ride vehicle for 5–7 minutes to en-
sure that th
e engine is at its operating temper-
ature. If oi
l level is verified when vehicle is not
at operatin
g temperature, oil level must be be-
tween lowe
r and upper marks on dipstick.
NOTICE
Never add oil in the engine if the ver-
ification is performed when the engine is cold.
1. Park the vehicle on a level surface.
2. Remove the LH middle side panel as follows:
2.1 Pull pane
l out of its grommets at the front
then unho
ok the rear.
rmr2010-038-003_a
1. Middle side panel
3. With the engine already at normal operating
temperature, start engine and let it run for at
least 30 seconds.
NOTE: Running engine for at least 30 seconds al-
lows the suction oil pump to drain the oil from the
engine crankcase back into the oil tank. Not carry-
ing out this step could result in overfilling the en-
gine oil.
4. Stop engine.
5. Unscrew and remove the oil dipstick.
22 / 39 2010-1 PREDELIVERY
