ADJUSTMENTS
rmr2008-029-003
FRONT SUSPENSION CAM ADJUSTMENT
rmr2008-030-004_c
A. Smooth adjustme nt (position 1)
B. Hard adjus
tment (position 5)
RECOMMENDED FRONT SHOCK ADJUSTMENT
LOAD
CAM
POSITION
68 kg (150 lb) rider 1, 2
91 kg (20
0 lb) rider
3
68 kg (150 lb)) rider with cargo 3
91 kg (200 lb) rider with cargo
4
Rider w
ith passenger and cargo
5
ACS Rea
r Suspension
Models Without Compressor (Manual
Adjustment)
The suspension pressure is adjustable by deflat-
ingorinflatingtheairspring. Useanaircompres-
sor and a pressure gauge.
To sof
ten suspension, reduce the air pressure and
to har
den suspension, increase air pressure.
1. Adjust the air spring as per the owner’s prefer-
ence.
2. Refer to the following chart for proper adjust-
ment.
MINIMUM PRESSURE 10 PSI / 70 kPa
Do not exceed recommended pressure by 10 PSI / 70 kPa
PASSENGER + CARGO (lb /kg)
LOAD
WARNING
DRIVER
Lb/Kg
0 100/45 150/70 200/90 250/115
PSI/kPa
PSI/kPa
PSI/kPa PSI/kPa
PSI/kPa
150/70 20/135
40/275 50/345 60/415
70/485
200/90 30/205
50/345
60/415
70/485
80/555
250/115
40/275
60/415 70/485 80/555
90/625
704902072
NOTICE
Do not exceed the maximum allowed
pressure. This might damage the air suspen-
sion.
NOTE: When adjusting the pressure, do not put
your weight on the vehicle and do not load cargo
in the storage compartment.
The air spring is connected directly to an air hose
with a schrader valve located under the seat.
rmo2010-001-056_a
1. Schrader valve
NOTE: On
models equipped with a remote adjust-
ment, it
is not necessary to adjust the suspension
setting
. The air s pring will inflate automatically at
the fac
tory setting after the vehicle start up. Re-
fer to t
he
2010 SPYDER RT OPERATOR'S GUIDE
for det
ails.
Lights
Headlights Aiming Verification
North A merican Models
1. Positi
on the vehicle 10 m (33 ft) in front of a test
surfa
ce (wall or screen).
28 / 39 2010-1 PREDELIVERY
