ENGLISH

♦ Injuries caused when changing any parts,

blades or accessories.

♦ Injuries caused by prolonged use of a tool.

When using any tool for prolonged periods

make sure you také regular breaks.

♦ Impairment of hearing.

♦ Health hazards caused by breathing dust

developer when using your tool (example:-

working with wood, especially oak, beech and

MDF).

Use

Adjusting the shoe plate for bevel cuts (ﬁ g. F)

The shoe plate (4) can be set to make either

a straight cut or a bevel cut at an angle of 45°.

♦ Loosen the screw (9) (approximately 3 full

turns).

♦ Lift the shoe plate (4) slightly and pull

backward, then rotate the shoe plate until the

slot in the shoe plate reaches the 45° position.

♦ Tighten the screw (9).

To reset the shoe plate (4) for straight cuts:

♦ Loosen the screw (9).

♦ Rotate the shoe plate (4) until the slot in the

shoe plate reaches the 0° position, then push

the shoe plate forwards.

♦ Make sure that the saw blade support roller (5)

is adjusted correctly.

♦ Tighten the screw (9).

Switching on and off

♦ To switch the tool on, press the on/off switch

(1).

♦ To switch the tool off, release the on/off switch

(1).

♦ For continuous operation, press the lock-on

button (2) and release the on/off switch (1).

♦ To switch the tool off when in continuous

operation, press and release the on/off switch

(1).

Sawing

Hold the tool ﬁ rmly with both hands while cutting.

The shoe should be held ﬁ rmly against the material

being cut. This will help prevent the saw from

jumping, reduce vibration and minimise blade

breakage.

♦ Let the blade run freely for a few seconds

before starting the cut.

♦ Apply only a gentle pressure to the tool while

performing the cut.

Hints for optimum use

Sawing laminates

When cutting laminates splintering may occur

which can damage the presentation surface. The

most common saw blades cut on the upward

stroke, therefore if the shoe plate is sitting on the

presentation surface either use a saw blade that

cuts on the downward stroke or:

♦ Use a ﬁ ne-tooth saw blade.

♦ Saw from the back surface of the workpiece.

♦ Clamp a piece of scrap wood or hardboard

to both sides of the workpiece to minimise

splintering, and saw through this sandwich.

Sawing metal

♦ Be aware that sawing metal takes much more

time than sawing wood.

♦ Use a saw blade suitable for sawing metal.

♦ When cutting thin sheet metal, clamp a piece

of scrap wood to the back surface of the

workpiece and cut through this sandwich.

♦ Spread a ﬁ lm of oil along the intended line of

cut.

Maintenance

Your Black & Decker tool has been designed to

operate over a long period of time with a minimum

of maintenance.

Continuous satisfactory operation depends upon

proper care and regular cleaning.

Warning! Before performing any maintenance

or cleaning, make sure that the tool is switched

off and unplugged and that the saw blade has

stopped.

♦ Regularly clean the ventilation slots in your tool

and charger using a soft brush or dry cloth.

♦ Regularly clean the motor housing using

a damp cloth. Do not use any abrasive or

solvent-based cleaner. Never let any liquid get

inside the tool and never immerse any part of

the tool into liquid.

Protecting the environment

Separate collection. This product must

not be disposed of with normal household

waste.

Should you ﬁ nd one day that your Black & Decker

product needs replacement, or if it is of no further

use to you, do not dispose of it with household

waste. Make this product available for separate

collection.
