Bosch DLE 40 [15/170] Maintenance and service

English | 15

Bosch Power Tools 2 609 140 582 | (14.7.11)

Sighting with the Alingment Aid (see figure E)

With the alignment aid 7, sighting over larger distances is a lot

easier. For this, look alongside the aligning aid on the top side

of the measuring tool. The laser beam runs parallel to this line

of sight.

Working with the Tripod (see figure C)

The use of a tripod is particularly necessary for larger distanc-

es. Position the measuring tool with the 1/4" thread 14 onto

the quick-change plate of the tripod 20 or a commercially

available camera tripod. Tighten the measuring tool with the

locking screw of the quick-change plate.

When positioning the tripod, observe that the measurement

will take place beginning from the rear or front edge of the

measuring tool, depending on the selected reference level.

Troubleshooting – Causes and Corrective Meas-

ures

The measuring tool monitors the correct

function for each measurement. When a de-

fect is determined, only the symbol shown

aside flashes in the display. In this case, or

when the above mentioned corrective

measures cannot correct an error, have the

measuring tool checked by an after-sales service agent for

Bosch power tools.

Accuracy Check of the Measuring Tool

The accuracy of the measuring tool can be checked as follows:

– Select a permanently unchangeable measuring section

with a length of approx. 3 to 10 metres; its length must be

precisely known (e.g. the width of a room or a door open-

ing). The measuring distance must be indoors; the target

surface for the measurement must be smooth and reflect

well.

– Measure the distance 10 times after another.

The deviation of the individual measurements from the mean

value must not exceed ±2.0 mm (max.). Log the measure-

ments, so that you can compare their accuracy at a later point

of time.

Maintenance and Service

Maintenance and Cleaning

Store and transport the measuring tool only in the supplied

protective pouch.

Keep the measuring tool clean at all times.

Do not immerse the measuring tool in water or other fluids.

Wipe off debris using a moist and soft cloth. Do not use any

cleaning agents or solvents.

Maintain the reception lens 19 in particular, with the same

care as required for eye glasses or the lens of a camera.

If the measuring tool should fail despite the care taken in man-

ufacturing and testing procedures, repair should be carried

out by an authorised after-sales service centre for Bosch pow-

er tools. Do not open the measuring tool yourself.

In all correspondence and spare parts orders, please always

include the 10-digit article number given on the type plate of

the measuring tool.

In case of repairs, send in the measuring tool packed in its

protective pouch 24.

Cause Corrective Measure

Temperature warning indicator (b) flashing; measure-

ment not possible

The measuring tool is outside the

operating temperature range from

– 10 °C to + 50 °C (in the function

continuous measurement up to

+40 °C).

Wait until the measuring

tool has reached the op-

erating temperature

Battery low indicator (a) appears

Battery voltage decreasing (meas-

urement still possible)

Replace batteries

Battery low indicator (a) flashing; measurement not pos-

sible

Battery voltage too low Replace batteries

“Error” and “––––” indication in display

The angle between the laser beam

and the target is too acute.

Enlarge the angle be-

tween the laser beam

and the target

The target surface reflects too in-

tensely (e.g. a mirror) or insuffi-

ciently (e.g. black fabric), or the

ambient light is too bright.

Work with the laser tar-

get plate 22 (accessory)

The laser beam outlet 18 or the re-

ception lens 19 are misted up

(e.g. due to a rapid temperature

change).

Wipe the laser beam out-

let 18 and/or the recep-

tion lens 19 dry using a

soft cloth

Calculated value is greater than

99999 m/m

Divide calculation into

intermediate steps

“Error” indication flashes at in display (top)

Addition/Subtraction of measured

values with different units of meas-

ure

Only add/subtract

measured values with

the same units of meas-

ure

Unreliable measuring result

The target surface does not reflect

correctly (e.g. water, glass).

Cover off the target sur-

face

The laser beam outlet 18 or the re-

ception lens 19 are covered.

Make sure that the laser

beam outlet 18 or the re-

ception lens 19 are un-

obstructed

Measuring result not plausible

Wrong reference level set Select reference level

that corresponds to

measurement

Obstruction in path of laser beam Laser point must be

completely on target

surface.

Cause Corrective Measure

OBJ_DOKU-27402-001.fm Page 15 Thursday, July 14, 2011 10:43 AM
