30D-Link DNS-343 User Manual

Section 3 - Conﬁguration

The user is now listed in the Users in group list.

To delete a user from a group, under Group Setting:

• Select the group

• Highlight the user to be removed

• Click the <<Remove button

To remove a user or group from the User or Group lists, click the trash can icon of that group or user.

To change a user password, click the notepad icon of the user.
