D-Link DNS-343 [60/86] The dns 343 download scheduling configuration will appear

60D-Link DNS-343 User Manual

Section 3 - Conﬁguration

Type admin for the username

and leave the password ﬁeld

blank.

Click Schedule Downloads.

The DNS-343 login screen will appear:

The DNS-343 Download Scheduling conﬁguration will appear.
