67D-Link DNS-343 User Manual
Section 3 - Configuration
The following printer driver messages will appear:
Click Yes to continue.
Click OK to continue and select
a printer driver.
Select the appropriate printer driver from the
list and click OK to complete the wizard. If the
driver is not in the list, select Have Disk.
