English | 17
Bosch Power Tools 2 609 140 699 | (3.12.09)
Protect the battery against heat, e. g.,
against continuous intense sunlight,
fire, water, and moisture. Danger of
explosion.
f In case of damage and improper use of the
battery, vapours may be emitted. Provide
for fresh air and seek medical help in case
of complaints. The vapours can irritate the
respiratory system.
f Use the battery only in conjunction with
your Bosch power tool. This measure alone
protects the battery against dangerous over-
load.
f Use only original Bosch batteries with the
voltage listed on the nameplate of your
power tool. When using other batteries, e. g.
imitations, reconditioned batteries or other
brands, there is danger of injury as well as
property damage through exploding batter-
ies.
Functional Description
Read all safety warnings and all in-
structions. Failure to follow the
warnings and instructions may re-
sult in electric shock, fire and/or se-
rious injury.
While reading the operating instructions, unfold
the graphics page for the machine and leave it
open.
Intended Use
The machine is intended for driving in and loos-
ening screws and bolts as well as for tightening
and loosening nuts within the respective range
of dimension.
Product Features
The numbering of the product features refers to
the illustration of the machine on the graphics
page.
1 Screwdriver bit with ball catch*
2 Tool holder
3 Locking sleeve
4 “Power Light”
5 Fixture for carrying strap
6 Battery unlocking button
7 Battery*
8 Rotational direction switch
9 On/Off switch
10 Battery charge-control indicator
11 Handle (insulated gripping surface)
12 Universal bit holder*
13 Screwdriver bit*
*Accessories shown or described are not part of the
standard delivery scope of the product. A complete
overview of accessories can be found in our acces-
sories program.
Technical Data
Cordless Impact Screw-
driver
GDR 10,8-LI
Professional
Article number
3 601 JA6 9..
Rated voltage
V= 10.8
No-load speed
min
-1
0 – 2600
Impact rate
min
-1
0 – 3100
Maximum torque,
hard screwdriving
application accord-
ing to ISO 5393
Nm 105
Bolt size
M4 – M12
Max. screw dia.
mm 8
Tool holder
¼" hexagon
socket
Net weight
kg 0.96
Weight according
to EPTA-Procedure
01/2003
kg 1.0
Technical data determined with battery from delivery
scope.
Please observe the article number on the type plate of
your machine. The trade names of the individual ma-
chines may vary.
OBJ_BUCH-1066-001.book Page 17 Thursday, December 3, 2009 9:10 AM
