Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED.

ITEM NO.

Description QTY

ITEM NO.

Description QTY

1 Weight Stack Frame 1 34 Bearing Φ47*Φ25*12 6

2 Main Frame 1 35 Bushing 4

3 Bottom Cross Brace 1 36 Right Tie Rod End M16 2

4 Rear Cross Brace 1 37 Left Tie Rod End M16 2

5 Sway Bracket 1 38 Plug RT50*100 2

6 Assistant Bracket 1 39 Grip(Φ36*Φ28*450) 2

7 Joint Bracket 1 41 Cable End 1

8 Sway Pulley Bracket 1 42 Brass Washer Φ35*Φ25.4*2 3

9 Right Press Arm 1 43 Button 8

10 left Press Arm 1 44 Rear Shroud 1

11 Seat Pad Support 1 46 Front Shroud 1

12 Adjustable Support Sleeve 1 48 Top Front Shroud 1

13 Adjustable Support 1 53 Spacer Φ10*Φ14*20 1

14 Adjustable Foot plate 4 54 Big Washer Φ55*13 3

15 Top Plate 1 55 Aluminium Cap 2

16 Gas Spring(30Kg) 1 56 Aluminium Grip Cap 2

20 Selector Pin W/Coil 1 57 Aluminium Grip Ring 2

21 4.5" Pulley 5 58 Retainning Snap Ring(d=25) 1

22 Cable 1 59 Foot Sleeve 2

23 Back Pad 1 60 Weight Rubber Bumper 2

24 Seat Pad 1 61 Plug Bumper 3

25 Spacer Φ24*Φ18*Φ11*9 2 62 Wheel 2

26 Rod Φ25*444*M16 2 63 Spring 1

27 Guide RodΦ19*1177 2 64 Plastic Tube Guide 2

28 Nut 2 65 Plug □25*50 1

29 Pivot Axle A(Φ25.4*Φ12.2*92) 1 66 Plug □44.5 1

30 Pivot Axle B(Φ25.4*Φ12.5*57) 1 67 Pulley Cover 3

31 Pivot Axle C(Φ19.05*Φ12.5*69) 1 68 Flat Washer Φ13*Φ24*1.5 6

32 Bearing Φ35*Φ19.1*13.5 2 69 Flat Washer Φ38*Φ11*2 3

33 Bearing Φ50.8*Φ25.4*15.9 2 70 Flat Washer Φ11*Φ20*2 34
