ITEM NO.

Description QTY

ITEM NO.

Description QTY

71 Flat Washer Φ9*Φ16*1.6 3 101 Hex Key s=6 1

73 Hex Nut M16 (Right) 2 102 Hex Key s=8 1

74 Hex Nut M16 (Left) 2 103 Hex Key s=12 1

75 Hex Nut M6 2 104 Hex Key s=3/32" 1

76 Nylon lock Nut M12 3 105 Wrench 1

77 Nylon lock Nut M10 15 106 Lube 1

78 Nylon lock Nut M8 2 107 Hex Key s=4 1

79 Hex Head Bolt M12*120 1 108 Rivet Nut M8 2

80 Hex Head Bolt M12*100 1 109 Rubber Plug Φ29*Φ19*10 2

81 Hex Head Bolt M12*85 1 110 Spring Washer Φ8 2

82 Hex Head Bolt M10*55 1 113 Flat Washer Φ9*Φ22*1.6 2

83 Hex Head Bolt M10*135 2 123 Hex Head Bolt M8*30 2

84 Hex Head Bolt M10*100 2 131 Socket Set Screw M6*15 2

85 Hex Head Bolt M10*50 4 132 Hex Key s=3 1

86 Hex Head Bolt M10*30 6 133 Hex Head Bolt M10*75 2

87 Hex Head Bolt M10*25 1 137 Shroud clip 12

88 Hex Head Bolt M10*20 2 138 Plastic Cover 1

Button Head Cap Screw M10*65

2 140 Support 1

Button Head Cap Screw M10*25

3 141 Top Cover 1

91 Button Head Cap Screw M8*55 1 142 Left Plug 1

92 Button Head Cap Screw M6*12 2 143 Right Plug 1

Socket Head Cap Screw M16*40

4 147 4.5" Pulley for Sensor 1

Socket Head Cap Screw M10*50

2 148 Plate for sensor 1

95 Socket Head Cap Screw M8*30 1 149 Philips Screw M3*8 4

96 Flat Head Cap Screw M10*30 4 150 Sensor 2

97 Screw M5*12 9 151 Console PCB 1

98 Rivet Nut M5 5 152 Cover for Magnetic Iron 1

99 Socket Set Screw 10-32*3.2 4 153 Magnetic Iron 2

100 Hex Key s=5 1 154 Screw ST2.9*9.5 2

─ 6 ─

Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED.
